MTX-DIN Family
4.3 GSM/GPRS antenna connector
The antenna connector allows radio frequency (RF) transmission signals between the modem and an
external customer-supplied antenna. The modem is fitted with a 50Ω, FME male coaxial jack.
The external antenna must be properly matched to achieve the best performance regarding radiated
power, DC-power consumption, modulation accuracy and harmonic suppression.
/
www.mtx-terminals.com
www.mtxm2m.com
2015/10 v2.3
Page 58
103
MTX M2M® by MATRIX ELECTRONICA S.L.U
