1.5.7 RF antenna interface description (2G models)

The table below briefly summarizes the RF Antenna interface GSM/UMTS
Parameter
Frequency range
Uplink (MS → BTS)
Frequency range
Uplink (BTS → MS)
RF Power @ ARP with 50Ohm Load
Number of carriers
Duplex spacing
Carrier spacing
Multiplex, Duplex
Time slots per TDMA frame
Frame duration
Time slot duration
Modulation
Static Receiver Input Sensitivity @
ARP
1. Power control level PCL 5
2. Power control level PCL 0
www.mtx-terminals.com
Conditions
GSM 850
EGSM 900
GSM 1800
GSM 1900
GSM 850
EGSM 900
GSM 1800
GSM 1900
GSM 850
1
EGSM 900
2
GSM 1800
GSM 1900
GSM 850
EGSM 900
GSM 1800
GSM 1900
GSM 850
EGSM 900
GSM 1800
GSM 1900
GSM 850
EGSM 900
GSM 1800
GSM 1900
www.mtxm2m.com
MTX M2M® by MATRIX ELECTRONICA S.L.U
MTX-DIN Family
Min. Typical Max.
824 849
880 915
1710 1785
1850 1910
869 894
925 960
1805 1880
1930 1990
31 33 35
31 33 35
28 30 32
28 30 32
124
174
374
299
45
45
95
80
200
TDMA/FDMA, FDD
8
4.615
577
GMSK
-102 -108
-102 -108
-102 -107
-102 -107
