for industrial GSM applications.
The memory space available for Java programs is around 1.7MB in the flash file system and around
6MB RAM. Application code and data share the space in the flash file system and in RAM.
SIM Application
SAT Release 99
Toolkit
TCP/IP stack Access by AT commands
MTX-DIN-2G supports Remote SIM Access. RSA enables MTX-DIN-2G to use a remote SIM card via its
serial interface and an external application, in addition to the SIM card locally attached to the
Remote SIM modem. The connection between the external application and the remote SIM card can be a
Access Bluetooth wireless link or a serial link. The necessary protocols and procedures are implemented
according to the "SIM Access Profile Interoperability Specification of the Bluetooth Special Interest
Group"
Firmware update Firmware update from host application over RS232/USB. Over-the-air (OTA) firmware is also possible.
Interfaces (depending on models)
USB Supports a USB 2.0 High Speed (480Mbit/s) device interface, Full Speed (12Mbit/s) compliant
RS232 (4-wires) Adjustable baud rates: 1200bps to 921600bps
Autobauding: 1200 to 230400bps
Supports RTS/CTS hardware flow control
Multiplex ability according to GSM 07.10 Multiplexer Protocol
RS422 Adjustable baud rates: 1200bps to 921600bps
Autobauding: 1200 to 230400bps
Multiplex ability according to GSM 07.10 Multiplexer Protocol
RS485 Adjustable baud rates: 1200bps to 921600bps
Autobauding: 1200 to 230400bps
Half-duplex
I2C interface Supports I2C serial interface up to 400kbps
GPIO 2x Optoisolated input/outputs and 4 Optoisolated inputs
ADC 2x analog-to-digital converters
DAC 1x digital-to-analog converter
Relays 4x form C switching contacts relays
Status 2x status LEDs (GSM status and user programmable
UICC interface Supported chip cards: UICC/SIM/USIM 3V, 1.8V
Antenna 50 Ohms. GSM/UMTS main antenna
Power on/off, Reset
Power on/off Automatic switch-on at power supply
Switch off by AT command
Switch off by hardware signal TURN_OFF
Automatic switch-off in case of critical temperature or voltage conditions
Software Reset Orderly shutdown and reset by AT command
Special features
Antenna SAIC (Single Antenna Interference Cancellation) / DARP (Downlink Advanced Receiver Performance)
Rx Diversity (receiver type 3i – 64-QAM) / MIMO
