HOBO® RX3000 Remote Monitoring Station Quick Start
RX3000 Station Key Components
LCD
Select
button
Ethernet
port
(RX3001
model)
USB port
Charging port
Battery port, cable connected
1
Log in to HOBOlink.
Log into an existing account at www.hobolink.com or create a
new one. You'll receive an email to activate the new account.
2
Register the station.
In HOBOlink, click Devices, RX Devices, and then the Register a
Device link. Give the station a name and enter the serial number
and device key from the label inside the station door.
3
Install optional modules or user-supplied SIM.
Ensure the station is powered off (unplug charging device and
then disconnect the battery). Insert optional RXMOD-x analog,
relay, water level sensor, or RXW Manager modules into the
Module 1 or 2 slot by plugging the connector into the receptacle
on the station. Screw the module in place with the provided
screw. If there is just one relay module, install it on the right.
If you installed an RXW Manager module, plug the cable from the
RXW Manager mote into the jack on the module, making sure the
cable is inserted through the upper cable access opening on the
bottom of the station case. Do not reconnect the power on the
station until the mote is plugged in as shown.
WARNING: If you inadvertently install modules while the power
is on, you must disconnect and then reconnect the battery and
charging device to guarantee proper operation.
18254-J MAN-QSG-RX3000
Start/
Stop
button
Connect/
Search
button
Slots for
optional user-
installed
modules
Insert the connector on
the module here
Note: If you are using your own SIM card, follow the instructions
at https://www.onsetcomp.com/support/manuals/installing-sim-
rx3000-station before continuing.
4
Plug in the battery and charging device.
Connect the battery port connector followed by the appropriate
charging port connector. Once the battery cable is plugged in,
"Initializing System" will flash on the LCD. A checkmark appears
next to "System" after the system initialization is complete.
Tip: Refer to the RX3000 manual for instructions on wire routing
and environmental sealing of wires.
5
Check or configure device communications.
For RX3003 or RX3004 cellular models:
The station will automatically connect to HOBOlink after powering
up the station in the previous step. Continue to step 6.
A checkmark
appears next
to Last
Connection
after
connecting to
HOBOlink
For RX3001 Ethernet models:
a. Plug in the Ethernet cable.
Note: The RX3001 Ethernet station is automatically configured
to use DHCP. If your network uses static IP addresses, contact
your Network Administrator for the correct addresses and
follow the Ethernet configuration steps in the RX3000 manual
at www.onsetcomp.com/manual/rx3000.
b. Press the Connect button (under the cloud icon) on the station
to connect to HOBOlink. Wait for a checkmark to appear next
to Last Connection as shown in the example in this step.
For RX3002 Wi-Fi models:
a. Connect the station to the computer with the USB cable.
b. In HOBOware 3.7.2 or later, select Manage RX Station from the
Device menu. (Select Domain networks and click Allow Access
if you see a Windows® Firewall warning.)
c. In the RX Station Manager, click the Actions button and select
Network Access.
d. Enter the Security information for your Wi-Fi network. Type
the Network Name, select the Security Type, and type the
Security Key. Consult your Network Administrator or wireless
router documentation for help with determining your network
security type.
Note: The station uses DHCP by default. If your network uses
static IP addresses, contact your Network Administrator for the
correct addresses to enter in the Networking fields.
e. Click Save in the RX Station Manager. Click Done and then
close the RX Station Manager.
f. Disconnect the USB cable.
g.
Press the Connect button (under the cloud icon) on the station
to connect to HOBOlink. Wait for a checkmark to appear next
to Last Connection as shown in the example in this step.
Connect button
