HOBO® MX pH and Temperature Logger (MX2501) Manual
HOBO MX pH and
Temperature Logger
MX2501
Included Items:
• pH electrode installed and
submerged in storage
solution
• Extra electrode storage
solution
• Anti-biofouling copper
guard
• Silicone-based O-ring
grease and foam swab
Required Items:
• HOBOconnect app
• Mobile device with
Bluetooth and iOS,
iPadOS®, or Android™
• Deionized or distilled water
and squirt bottle
• Calibration solutions
Accessories:
• Replacement pH electrode
(MX2500-ELECTRODE)
• Calibration kit with three
bottles: pH 4.01, 7.00, and
10.00 calibration solution
(MX2500-CAL-KIT) and
calibration beakers
(MX2500-CAL-BKR)
• Maintenance kit with
calibration kit plus storage
solution (MX2500-MAINT-
KIT)
• pH 4.01 calibration solution
(MX2500-CAL-4)
• pH 7.00 calibration solution
(MX2500-CAL-7)
• pH 10.00 calibration
solution (MX2500-CAL-10)
• Electrode storage solution
(MX2500-STORE-SOLN)
• Replacement sensor end
cap (MX2500-END-CAP)
• Replacement anti-
biofouling copper guard
(MX2500-GUARD)
• Replacement clear storage
cap (MX2500-STORAGE-
CAP)
22511-O
The HOBO MX pH and Temperature logger is designed for long-term monitoring of pH in
aquatic systems. With a replaceable pH electrode and anti-biofouling copper guard, this
durable logger can be deployed in both fresh and salt water environments. This logger is
Bluetooth® Low Energy-enabled for wireless communication with a mobile device. Using the
HOBOconnect™ app, you can easily calibrate and configure the logger, download logged data to
your phone or tablet, or automatically upload the data to HOBOlink® for further analysis. You
can also configure the logger to calculate statistics, set up alarms to trip at specific thresholds,
or enable burst logging in which sensor readings are logged at a faster interval when the pH or
temperature rises above or falls below certain limits.
Specifications
pH Sensor
Range
Accuracy
Resolution
Response Time
Sample Ionic Strength
Temperature Sensor
Range
Accuracy
Resolution
Response Time
Logger
Operating Range
Buoyancy
Waterproof
Water Detection
Radio Power
Transmission Range
Wireless Data Standard
Logging Rate
Logging Modes
Memory Modes
Start Modes
Stop Modes
Time Accuracy
Battery Type
in pH
2.00 to 12.00 pH
±0.10 pH units within ±10°C of
temperature at calibration
0.01 pH
1 minute typical to 90% at constant temperature in stirred water
≥ 100 µS/cm
-2° to 50°C (28.4° to 122°F)
±0.2°C (±0.36°F)
0.024°C at 25°C (0.04°F at 77°F)
7 minutes typical to 90% in stirred water
-2° to 50°C (28.4° to 122°F) — non-freezing
Fresh water: 13.6 g (0.48 oz) negative
Salt water: 19.6 g (0.69 oz) negative
To 40 m (131.2 ft)
Water conductivity level of 100 µS/cm or greater is necessary for
reliable detection of water. Deionized water or water below 100 µS/cm
may not be detected.
The water conductivity circuit may not reliably detect water that has
frozen around the electrodes, i.e. below 0°C (32°F).
1 mW (0 dBm)
Approximately 30.5 m (100 ft) line-of-sight in air
Bluetooth Low Energy (Bluetooth Smart)
1 second to 18 hours
Fixed interval (normal, statistics) or burst
Wrap when full or stop when full
Immediate, push button, date & time, or next interval
When memory is full, push button, date & time, or after a set logging
period
±1 minute per month 0° to 50°C (32° to 122°F)
One AA 1.5 Volt, user-replaceable
in mV
-512 to 512 mV
±0.20 mV
0.02 mV
