HOBO® RX3000 Remote Monitoring Station Quick Start
RX3000 Station Key Components
LCD
Select
button
Ethernet
port
(RX3001
model)
USB port
Charging port
Battery port, cable connected
1

Log in to HOBOlink.

Go to www.hobolink.com and log into an existing account or
create a new one. You'll receive an email to activate the new
account.
2

Register the station.

In HOBOlink, click Devices and then click the Register a Device
link. Give the station a name and enter the serial number and
device key from the label inside the station door.
3

Install optional modules or user-supplied SIM.

Ensure the station is powered off by pulling the battery and
charger connections. Insert optional RXMOD-x analog, relay, or
RXW Manager modules into the Module 1 or Module 2 slot by
plugging the connector into the receptacle on the station. Screw
the module in place with the provided screw. If there is just one
relay module, install it on the right.
If you are installing an RXW Manager module, plug the cable from
the RXW Manager mote into the jack on the module, making sure
the cable is inserted through the bottom of the station case. Do not
reconnect the power on the station until the mote is plugged in as
shown.
WARNING: If you inadvertently install modules while the power is
on, you must disconnect and then reconnect the battery and
charging device to guarantee proper operation.
18254-I MAN-QSG-RX3000
Start/
Stop
button
Connect/
Search
button
Slots for
optional user-
installed
modules
Insert the connector on
the module here
Note: If you are using your own SIM card, follow the instructions
at https://www.onsetcomp.com/support/manuals/installing-sim-
rx3000-station before continuing.
4

Plug in the battery and charging device.

Connect the battery port connector followed by the appropriate
charging port connector. Once the battery cable is plugged in,
"Initializing System" will flash on the LCD. A checkmark appears
next to "System" after the system initialization is complete.
Tip: Refer to the RX3000 manual for instructions on wire routing
and environmental sealing of wires.
5

Check or configure device communications.

For RX3003 or RX3004 cellular models:
The station will automatically connect to HOBOlink after powering
up the station in the previous step. Continue to step 6.
A checkmark
appears next
to Last
Connection
after
connecting to
HOBOlink
For RX3001 Ethernet models:
a. Plug in the Ethernet cable.
Note: The RX3001 Ethernet station is automatically configured
to use DHCP. If your network uses static IP addresses, contact
your Network Administrator for the correct addresses and
follow the Ethernet configuration steps in the RX3000 manual
at www.onsetcomp.com/manual/rx3000.
b. Press the Connect button (under the cloud icon) on the station
to connect to HOBOlink. Wait for a checkmark to appear next
to Last Connection as shown in the example in this step.
For RX3002 Wi-Fi models:
a. Connect the station to the computer with the USB cable.
b. In HOBOware 3.7.2 or later, select Manage RX3000 from the
Device menu. (Select Domain networks and click Allow Access
if you see a Windows® Firewall warning.)
c. In the RX3000 Manager, click the Actions button.
d. Enter the Security information for your Wi-Fi network. Type
the Network Name, select the Security Type, and type the
Security Key. Consult your Network Administrator or wireless
router documentation for help with determining your network
security type.
Note: The station uses DHCP by default. If your network uses
static IP addresses, contact your Network Administrator for the
correct addresses to enter in the Networking fields.
e. Click Save in the RX3000 Manager. Click Done and then close
the RX3000 Manager.
f. Disconnect the USB cable.
g.
Press the Connect button (under the cloud icon) on the station
to connect to HOBOlink. Wait for a checkmark to appear next
to Last Connection as shown in the example in this step.
Connect button
