Wood-Mizer
Safety, Setup, Operation
& Maintenance Manual
LT60AHD
LT70AHD
Safety is our #1 concern! Read and understand all
!
safety information and instructions before operating,
setting up or maintaining this machine.
®
Sawmill
rev. A3.01
rev. A3.01
June 2002
Form #1051
