Adult Malibu - 3+2 Wardrobe
Assembly Instructions -
More help is available throughout this booklet by scanning
Dimensions
Width - 74.8cm
Depth - 49.8cm
Height - 180.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please keep for future reference
in the QR codes or typing in the links
C R
C R
C R
553/2724
555/9518
543/5041
560/9712
558/3924
531/3637
555/3057
544/0366
555/8722
557/1730
MADE IN
BRITAIN
Issue 1 - 18/05/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Adult Malibu
Summary of Contents for Argos Adult Malibu
- Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 50kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
- Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 5 Components - Fittings Individual Fittings Bags Overbalance protector kit ( F474) Handle (F418) Pre-mounted hinge ( F419) 436mm long Drawer Brace (F427) CL Runner (F608) 450mm long CR Runner (F609) DL Runner (F610) DR Runner (F611)
- Page 6 Assembly Instructions Step 1 Use the Drawer Fittings Bag marked ‘drw kit’ for Steps 1 - 7 Prepare the drawer Standard Drawer Box Assembly sides https://www.youtube.com/watch?v=HclfJdkm-Lg Insert a large locking cam nut into the left drawer sides and the right drawer sides Note: The arrow on the locking cam nut must point towards the...
- Page 7 Assembly Instructions Step 3 Fit the drawer bases Slide a drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 4 Fit the drawer backs Fit a drawer back between the drawer sides Make sure that the drawer base...
- Page 8 Assembly Instructions Step 6 Fit the drawer braces Turn the 3 drawer assemblies over and hook a drawer brace onto the bottom edge of the drawer back Fix it to the drawer front and drawer back using 2 screws Fixing Bottom Mounter Runners Step 7 https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit runners to the...
- Page 9 Assembly Instructions Step 8 Use the Main Fittings Bag for Steps 8 - end Prepare the left side Fixing Bottom Mounter Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit 3 CL runners to the left side screw The 1st screw uses the 1st hole in from the front of the runner.
- Page 10 Assembly Instructions Step 9 Prepare the right side screw Fit 3 CR runners to the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws Finished use the holes that line front edge up with the other panel holes.
- Page 11 Assembly Instructions Step 10 Prepare the horizontal Insert 4 large locking cam nuts into the horizontal Push 4 of the quickfit Finished dowels as far as they front edge will go into the horizontal Tap 6 wooden dowels into the horizontal Step 11 Carcase Assembly https://www.youtube.com/watch?v=9C7tgv5xnbE...
- Page 12 Assembly Instructions Step 13 Fit the 2 cross rails to the right side Push the 2 cross rails onto the right side shown. Finished front edge Finished front edge Step 14 Prepare the 2 plinths and the back rail Insert 2 large locking cam nuts into the each of the 2 plinths...
- Page 13 Assembly Instructions Step 15 Fit the 2 plinths and the back rail Finished top edge Push the 2 plinths and the back rail onto the right side Turn the 3 large locking cam nuts clockwise as far as they will go to secure the panels.
- Page 14 Assembly Instructions Step 17 Fit the top Push the top onto the assembly. Turn the 4 large locking cam nuts clockwise as far as they will go to secure the panels. Important: Make sure there is no gap between the fitted panels. Finished front edge Squaring up a Robe and tting the Back Panel...
- Page 15 Assembly Instructions Step 19 Fit the 5 plastic nails Tap 2 plastic nails into the bottom edge of each side Tap the remaining plastic nail into the bottom edge of the plinth the front of the unit. Carefully stand the unit up for the next step and place it in its final position in the...
- Page 16 Assembly Instructions Step 20 Fit the overbalance protector kit Before fitting the overbalance protector kit, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level.
- Page 17 Assembly Instructions Fixing Bottom Mounter Runners Step 21 https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit the hanging rail and drawers Push the hanging rail into the rail holders fitted to the side panels. Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position.
- Page 18 Assembly Instructions Pre-mounted Hinge Fitting & Adjustment Step 23 https://www.youtube.com/watch?v=b4NeCGnpjP8 Fit the doors and the handles When the hinges have Press the screws into been pushed in, the holes in the panels 2 people are needed tighten up their screws here Fit 1 door a time, by lining up the 2...
- Page 19 Assembly Instructions Step 24 Pre-mounted Hinge Fitting & Adjustment https://www.youtube.com/watch?v=b4NeCGnpjP8 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown.
- Page 20 2 doors Assembly is complete If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
