Alicia - 3 Drawer Chest
Assembly Instructions -
Dimensions
Width - 53.5cm
Depth - 39.5cm
Height - 65.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
152/3799
151/3084
MADE IN
BRITAIN
Issue 2 - 06/02/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Alicia
Summary of Contents for Argos Alicia
- Page 1 Alicia - 3 Drawer Chest Assembly Instructions - 152/3799 Please keep for future reference 151/3084 Dimensions Width - 53.5cm Depth - 39.5cm MADE IN Height - 65.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2662A) (D2663A) (D2683A) (637 x 393mm) (637 x 393mm) (533 x 395mm) Rail...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 3 drawer fronts Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten the metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the drawer assemblies over. Slide a wedgefix into the small groove in the drawer front , drawer back and drawer sides , as shown. Once in place, tighten up the screws. Step 8 Prepare the left side Place 3 runners the left side...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place 3 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 10 Prepare the 2 rails Tap 2 wooden dowels into each of the rails Note: Wooden dowels must not stick out from 10mm the edge by more than 10mm or they may damage other panels. Insert 2 large locking nuts into each of the rails...
- Page 10 Assembly Instructions Step 12 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to the rails Finished front edge Step 13 Prepare the top Screw 4 metal dowels into the top Finished front edge...
- Page 11 Assembly Instructions Step 14 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the left side and right side Finished front edge Step 15 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by...
- Page 12 If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2945...
