Installation manual
CONTENTS
PRECAUTION..................................................................1
INSTALLATION PLACE............................................................................1
ACCESSORIES........................................................................................2
INTDOOR UNIT INSTALLATION ..............................................................2
SPACE............................................................................4
PIPE.............................................................................4
DESIGN.......................................................................................4
PIPE..........................................................6
CONNECTION........................................................6
PIPE...................................................................8
WIRING.................................................................................................8
CONTROL..............................................................................................9
TROUBLE SHOOTING............................................................................11
INSTALL ELECTRIC THROTTLE PART...................................................11
INSTALL BRANCH PIPE.........................................................................11
TEST OPERATION..................................................................................12
FRESH AIR HARDING UNIT CONFIGURATION INSTRUCTIONS..............12
1. INSTALLATION PRECAUTION
To install properly, please read this manual at first.
The air conditioner must be installed by qualified persons.
When installing the indoor unit or its tubing, please follow this
manual as strictly as possible.
When all the installation work is finished, please turn on the power
only after a thorough check.
No further announcement if there is any change of this manual
caused by product improvement.
The installor should illustrate to users how to correctly use
and maintain the air-conditioner, as well as remind users to
carefully read and keep both Installation Manual and Owner's
Manual well.
DISPOSAL Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for special treatment
is necessary.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
esperience and knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
Disconnect the power supply before cleaning and maintenance.
The appliance must be installed 2,3m above floor.
The appliance shall not be installed in the laundry.
NOTE
CAUTION
If the supply cord is damaged, it must be replaced by the
PAGE
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
An all-pole disconnection switch having a contact separation of
at least 3mm in all poles should be connected in fixed wiring.
The appliance shall be installed in accordance with national
wiring regulations.
The temperature of refrigerant circuit will be high, please keep
the interconnection cable away from the copper tube.
An all-pole disconnection device which has at least 3mm
separation distance in all pole and a residual current
device(RCD)with the rating of above 10mA shall be incorporated
in the fixed wiring according to the national rule.
The power cord type designation is H05RN-R/H07RN-F or above.
2. INSTALLATION PLACE
Indoor Unit
●
Enough room for installation and maintenance.
●
The ceiling is horizontal and it can afford the weight of the indoor
unit.
●
The air inlet and outlet are not impeded and does not affected by
outdoor air too much.
●
The air flow can reach every part of the room.
●
The connecting pipe and drainpipe can be easily extracted out.
●
There is no direct radiation from heat source.
Outdoor Unit
●
Enough room for installation and maintenance.
●
The air inlet and outlet are not impeded and does not affected by
outdoor air too much.
●
Dry and well ventilated place.
●
The supporter is flat and horizontal and can afford the weigh of
outdoor unit, without noise and vibration.
●
The noise and the outlet air will not influence your neighbor.
●
No combustible gas.
●
Place convenient for piping and wiring.
●
Please keep away from the following places, or malfunction may
be caused.(if unavoidable, please consult the professionals):
There is mineral oil like the oil of cutting machine.
●
There is much salty air. (Near the coast)
●
There is caustic gas such as sulfuric gas. (Near the hotspring.)
●
Factory where the voltage fluctuate greatly.
In the car or in the cabin.
●
●
In the kitchen or a place full of oil steam.
There is strong electromagnetic wave.
●
●
There is combustible gas or materials.
1
High pressure duct D4+
