- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Applied Functions Instruction Manual 3506-10 C METER July 2013 Edition 1 3506B984-00 13-07H...
-
Page 2: Table Of Contents
Contents Contents 目 次 Chapter 1 Overview ___________________________________ 1 Chapter 2 Using 4288A Commands______________________ 2 Commands Compatible with the Agilant 4288A ......2 Language Mode Setting .............2 Table of Commands Compatible with the 4288A .......3 Chapter 3 Monitor Measurement Signal _________________ 12 Current Detection Circuit Monitoring Function ......12 Applied Voltage Value Monitoring Function ......153 Chapter 4... -
Page 3: Overview
Chapter 1 Overview Application Functions Reference Function Description Section Language Mode Can carry out Agilant Technology 4288A commands. (p. 2) Current detection circuit monitoring Detects measured current abnormalities. (p. 12) function Applied voltage Detects measured voltage abnormalities. (p. 13) monitoring function Menu display organization Displays menu screen (MAIN display area) -
Page 4: Using 4288A Commands
“Err.Cur” (Current detection circuit monitoring function setting screen) will be shown in the MAIN display area. Press Returns to measurement mode before displaying the SUB menu screen. The device is initially set to “hioKi”... -
Page 5: Table Of Commands Compatible With The 4288A
Table of Commands Compatible with the 4288A Table of Commands Compatible with the 4288A 1. Measurement Conditions ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility Please refer to the corre-... - Page 6 Table of Commands Compatible with the 4288A 2. Circuit Compensation ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility Open Circuit Compensation :CORR:OPEN ON/ OFF/ 1/ 0 ON/ OFF...
- Page 7 Table of Commands Compatible with the 4288A 3. Scanner (Multi Compensation) ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility Compatible in panel load × ON/ OFF :CORR:MULT ON/ OFF/ 1/ 0 and save functions ×...
- Page 8 Table of Commands Compatible with the 4288A 5. Measurement data output ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility Data forwarding format setting :FORM ASCii/ REAL Data reading...
- Page 9 Table of Commands Compatible with the 4288A 6. Comparator Function ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility ON/ OFF setting :CALC:COMP ON/ OFF/ 1/ 0 Clear limit range setting :CALC:COMP:CLE ...
- Page 10 Table of Commands Compatible with the 4288A 7. Measurement Signal Level Monitor ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Com- 4288A Command Parameter Discrepancy patibility Monitor ON/ OFF :CALC3:MATH:STAT ON/ OFF/ 1/ 0 Always ON ...
- Page 11 Table of Commands Compatible with the 4288A 9. Display ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Com- 4288A Command Parameter Discrepancy patibility ON/ OFF setting :DISP ON/ OFF/ 1/ 0 Turns off all LEDs other than mode display and ...
- Page 12 Table of Commands Compatible with the 4288A 11.Beep output ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility ON/ OFF :CALC:COMP:BEEP ON/ OFF/ 1/ 0 :SYST:BEEP:STAT ON/ OFF/ 1/ 0 ...
- Page 13 Table of Commands Compatible with the 4288A 13.Other ：Fully compatible ：Partially compatible ×：Incompatible Agilent 4288A HIOKI 3506-10 Setting description Compati- 4288A Command Parameter Discrepancy bility Execute self test Internal Please refer to the corre- *TST? sponding instruction man- ...
-
Page 14: Monitor Measurement Signal
Current Detection Circuit Monitoring Function Chapter 3 Monitor Measurement Signal Current Detection Circuit Monitoring Function If the measurement range is set too low for the object being measured or the object being measured is in a SHORT state, a current wave outside the permissi- ble range is generated. -
Page 15: Applied Voltage Value Monitoring Function
Applied Voltage Value Monitoring Function Applied Voltage Value Monitoring Function The measurement signal level of this device is intended for the measurement terminals being open. Due to the influence of the device's output impedance, the voltage applied to the sample will be less than the set signal level. With this func- tion it can be detected as an error when the applied voltage is outside the set limit value. - Page 16 Applied Voltage Value Monitoring Function Press to confirm the limit value. LAnG “ ” (Language mode setting screen) will be displayed in the MAIN display area. is not pressed the applied voltage value monitoring function setting will not be set. Press Returns to measurement mode before displaying the SUB menu screen.
-
Page 17: Message Reference
:LANGuage <HIOKI/ 4288A> Query :LANGuage? Provides an explanation of the Response <HIOKI/ 4288A> HIOKI :Chooses standard language command data section or re- 4288A : Chooses Agilent 4288A language sponse data. Explanation Command Sets language mode Provides an explanation of the... - Page 18 1. Setteing and Query Language Mode Syntax :LANGuage Command <HIOKI/ 4288A> Query :LANGuage? Response <HIOKI/ 4288A> HIOKI : Chooses standard language. 4288A : Chooses Agilent 4288A language. Explanation Command Sets language mode. Query Returns the language mode setting as characters. :LANGuage 4288A Example Command Sets the language mode to 4288A.
- Page 19 Applied Voltage Value Monitoring Function 3. Setting and Query of the Applied Voltage Value Monitoring Function Syntax :VCHeck Command <ON/ OFF> Query :VCHeck? Response <ON/ OFF> : Starts monitoring of the applied voltage value. OFF : Stops monitoring of the applied voltage value. Explanation Command Enables or disables the applied voltage value monitoring function.
- Page 20 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com...
