KI Toggle ELC Assembly Instructions Manual

Detail A
M6 x 35 M8 x 12
socket head
button-head
cap screw machine screw
Figure 1
ATTENTION: Following assembly,
prior to being placed into service.
table to malfunction.
Table "Zero Setting" Press and hold the Up button for
:
two seconds then release. Next, press and hold the Down
button until table has reached its lowest position then release
Down button. Then, press the Down button again and hold for
approximately 10 seconds. The table now re-set at its "Zero
Setting" position and is ready to operate.
Assembly Instructions
Dual Motor C-Leg Adjustable-Height Base, Model ELC
M8 x 12
button-head
machine
screw
C-Leg
end-support
tube
socket head
cap screw
C-Leg
foot
leg-to-leg
spanners
column
table must be "zero set"
Failure to do so can cause
Toggle Tables
®
July 2024
adjustable
"
#10-24 x / 3
glide
8
Torx head
screws
non-locking
caster
locking
caster
foot
Detail B
adjustable
M6 x 35
glide
foot
plate
leg
M8 x 12
button-head
machine screw
set screw
holes
mounting
flange of
motor housing
cross-support
tube
end-support
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Adjustable-Height Base Assembly
1. Carefully remove contents from
packaging, set out on a soft, clean
surface and refer to Figure 1
to identify the parts required for
assembly.
2. Position the two cross-support tubes
(with mounting tabs facing down
and facing inwards), and one C-leg
end support tube out as illustrated.
Place a leg column assembly over
the three support tubes and align six
mounting holes of the leg column
with appropriate mounting holes of
the three tubes as illustrated. The
C-leg end support tube contains three
mounting holes but only the two
non-user side holes can be used.
Make sure the tube has the longer end
and one unused mounting hole, facing
the user side as illustrated (Detail A).
Using six M8 x 12 button head
machine screws torqued to 9.5 ft/lb,
secure the flange of the leg column to
the three support tubes (Figure 1).
3. Assemble the C-leg foot to the leg
column by first positioning a plastic
foot plate over the mounting location
on the leg column. The foot plate
must be oriented so the raised flange
faces into the column, to nest the foot
plate into place. Next, position a foot
over the foot plate and leg column as
illustrated, with the mounting holes of
the foot aligning with those of the leg
column. It is important that the longer
end of the C-leg foot face the user
side. Once foot is correctly oriented,
secure the foot to the leg column with
four M6 x 35 socket head cap screws.
Torque to 7.5 ft/lb (Figure 1).
4. If casters are required, twist both
adjustable glides out of the C-leg foot.
Locking and non-locking casters are
supplied. Locking casters should be
located toward the front, user side of
the table for easy access while the
non-locking casters are located to the
back. Using four #10-24 x
screws, carefully secure the casters to
C-Leg
the foot (Detail B).
tube
5. Repeat steps 2 & 3 for second leg
assembly and step 4 if casters are
required (Figure 1).
6. Position two leg-to-leg spanners
with channel opening face up, then
slide both spanners into the open
ends of each base tube of both base
assemblies. Slide bases together, but
do not secure with set screws at this
time (Figure 1).
/ " Torx
3
8
