TELECO AUTOMATION TVDLC868A01 Manual page 9

4
Modification of the preset light values of a 4 or 7/42 channel transmitter
If any transmitter with modified light values is used in the remote memorization (page 8), the added transmitter will have the same modified values.
1
CH1
CH2
CH3
CH4
CH5
CH6
CH7
1. Press the button relative to the value to modify (CH1..CH4). 2. Adjust the value with buttons CH5 and CH6. 3. Press CH7 and keep it pressed for 5s.
1
CH1
CH2
CH3
CH4
1. Press the button relative to the value to modify (CH1..CH4). 2. Adjust the value keeping pressed the same button. 3. Press CH4 and keep it pressed for 5s.
2
CH1
CH2
CH3
CH4
CH5
CH6
CH7
2
CH1
CH2
CH3
CH4
9
3
CH1
CH2
CH3
CH4
CH5
CH6
( 5 s)
CH7
3
CH1
CH2
CH3
CH4
(
Load
OFF ON
continuous sound
Load
OFF ON
continuous sound
5 s)
