Ezcap 159 USB 2.0 Video Capture
Quick Start Guide
This Ezcap159 USB 2.0 Video Capture device is intended for use on both Windows OS and Mac OS X 32 &
64bit. The software includes Honestech video capture and editing software VHS-DVD 5.0 SE for Windows OS.
Mac OS X will require you to capture video using Apple QuickTime Player.
Please familarise yourself with the OVERVIEW section, then go to the appropriate WINDOWS or MAC install
guide before making any connections. Please follow each step carefully
Important: If you have any previous versions of EzCap, ShowBiz or ArcSoft software on your device this must be
completely uninstalled using the original CD that came with that product
BOX CONTENTS
Ezcap 159 USB 2.0 Video Capture (dongle)
Software CD and Quick Start Guide
OVERVIEW
This product has universal connections for optional use of different devices, you will not use all the inputs.
You may require additional RCA / CVBS or S Video cable to connect from your device to the dongle.
To capture audio, connect the left and right composite RCA / Phono (red and white) to the corresponding colour
left and right audio outputs of your playback device or camera. Some devices may only have one (white) audio
output.
If you are using the round S-Video (black) input, you cannot use composite connections at the same time.
pg. 1 V2. gardenature.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EzCAP 159
Summary of Contents for EzCAP 159
- Page 1 Please follow each step carefully Important: If you have any previous versions of EzCap, ShowBiz or ArcSoft software on your device this must be completely uninstalled using the original CD that came with that product BOX CONTENTS Ezcap 159 USB 2.0 Video Capture (dongle)
- Page 2 1, Open honestech VHS to DVD 5.0 SE. You can find the software by double clicking the shortcut icon on your computer’s Desktop. 2, Capture Settings: Click the drop-down box next to Video Device and select ezcap USB video capture from the list.
- Page 3 Connect ezcap159 USB 2.0 Video Capture to a USB 2.0 port on your computer, the hardware should be auto installed to your computer. Click on the Apple LOGO – About this Mac – More info – Hardware – USB, “ezcap USB audio” should be seen in the list to indicate the driver has installed correctly.
