- Page 1 MANUAL INFRARED PANEL ENGLISH...
- Page 2 SAFETY INSTRUCTIONS • Read the Manual before installing and using the panels. • Covering the Heater causes fire hazard. • Do not allow children or people with mental disabilities to use or to stay inside IR sauna room without adult supervision. •...
- Page 3 Keep the manual in the vicinity of the device. SAWO IR panels are made from carbon plate. Fiber coating is added on the surface making it safe to touch. SAWO IR panels emit Far Infrared heat that is suggested to be beneficial for health.
- Page 4 It is recommended to use SAWO IR controller to achieve optimum setting. See to it that the breaker load is enough as needed. The cable must be H07RN-F type or equivalent. A qualified electrician must install the device. Improper wiring connection may cause damage to the IR panel, electric shock or fire.
- Page 5 Provide a backrest after installing the IR panel from the wall. This is to prevent damage of the IR panel from leaning into it. Fig. 4 Backrest ELECTRICAL DIAGRAM Fig. 5 130 °C 230VAC 1N~ 130 °C 50/60 Hz 230VAC 1N~ 50/60 Hz IR Panel 1 IR Panel 2...
- Page 6 CLEANING AND MAINTENANCE • The IR panel surface is fiber coated which makes it safe to touch. Never use wet cloth or wash the IR panel. Make sure to unplug the IR sauna room before cleaning. You may wipe a dry cloth or use a paint brush to remove dirt from the IR panel.
- Page 7 IR panel can be placed on the ceiling, walls or on the flooring. Be sure to follow the recommended distance of the IR panel installation (see fig. 7). When installing on the floor, make sure to provide a protection on the panel from people stepping into it when installing on the floor. Fig.
- Page 8 Max 340 W Sizes: IR-Panel-1: 325mm (L) x 630mm (H) x 30mm (D) IR-Panel-2: 645mm (L) x 630mm (H) x 30mm (D) Type: Far-infrared Surface: Fiber coated material Wavelength: 6000-14000nm IR-PANEL-1 IR-PANEL-2 Subject to change without notice. www.sawo.com | info@sawo.com...
