1. WARNINGS AND SAFETY NOTES
Discharging
The main purpose of discharging is to clean the residual capacity of the battery, or to reduce the
battery' voltage to a defined level. The same attention should be paid to the discharging process
as the charging process. The final discharge voltage should be set up correctly to avoid deep
discharging. Lithium batteries cannot be discharged to lower than the minimum voltage, or it
will cause a rapid loss of capacity or a total failure. Generally, lithium batteries don't need to be
discharged. Please pay attention to the minimum voltage of lithium batteries to protect them.
Some rechargeable batteries have a memory effect. If they are partly used and recharged
before the whole charge is accomplished, they remember this and will only use that part of their
capacity next time. This is a 'memory effect' It is said that NiMH and NiCD batteries are suffering
from memory effect. NiCD has more 'memory effect' than NiMH.
Lithium batteries are recommended to be discharged partially rather than fully (Please use the
recommended Storage Mode). Frequent full discharging should be avoided if possible. Instead,
charge the battery more often or use a battery of larger capacity. Full capacity cannot be
reached until it has been subjected to 10 or more charge cycles. The cyclic process of charge
and discharge will optimize the capacity of battery pack.v

2. SPECIFICATIONS

TYPE OF BATTERIES :
INPUT VOLTAGE :
INPUT CURRENT :
CHARGE CURRENT :
DISCHARGE CURRENT :
CHARGE POWER :
BALANCE CURRENT :
BALANCE PRECISION :
USB OUTPUT :
WEIGHT :
DIMENSION :
(2x) 1-6S LiPo / LiFe / LiIon / LiHV
(2x) 1-16 cells NiMH / NiCd
(2x) 2-24V PB
AC 100V - 240V 50HZ
DC 9 - 24V
MAX. 30A (2x 15A)
(2x) 0.1 - 16.0A
(2x) 0.1 - 3.0A
AC Max. 200W
DC Max. 400W (@input 16V)
Max. 1A
±0.01V
5V - 2A
720g
142×99×69.5mm
