DELTA -PEAK SENSITIVITY (∆V) for NiCD / NiMH batteries
Programming the Delta-Peak's sensitivity automatically stops the charging cur-
rent and terminates charging when the battery voltage has reached its maximum
and begins to decrease. If the Delta-Peak trigger voltage is set too high, an over-
charge hazard will result, if set too low, the processor will stop charging early.

DISPLAY INFO

Rotate the battery channel selection knob to change the content displayed in the
lower part of the screen.
The following information is displayed in turn: Voltage of each cell, Operating
specifications, Internal resistance of each cell.
Program CH1
Current
Final Capacity
Display working
status
Program Performing Time
Cell Voltage for each Cell
10
Program CH2
Current
Final Capacity
Display working
status
