BALANCE STATUS

During the charging process the display is green, it turns blue when charging
is completed. When charging is completed (blue screen), the difference in cell
voltage should be less than 10mV. The charger continues to perform accurate
balancing of the battery while the screen is blue.
Program Operation
Time
Current
Selected Program
Single cell voltage
shown

USER SETTING

While the charger is in standby mode, press the SELECT button to manually
configure the settings.
CH1 Output Power . . . . . AUTO, 10-200W Level
CH2 Output Power . . . . . AUTO, 10-200W Level
Min. Input Voltage . . . . . 9 - 24V DC
Back Light . . . . . . . . . . . Back Light settings: AUTO, HIGH, MEDIUM, LOW
Volume . . . . . . . . . . . . . Buzzer Volume settings: OFF, HIGH, MEDIUM, LOW
Language . . . . . . . . . . . 7 Languages
Update . . . . . . . . . . . . . . Connect to a computer to perform the update
System Information . . . System Self-checking
Back . . . . . . . . . . . . . . . Return to last menu
12
Battery capacity %
(calculated)
Capacity charged
