Ronda 1006 Technical Instructions

Ronda 1006 Technical Instructions

Advertisement

Quick Links

RONDA AG
Hauptstrasse 10
CH-4415 Lausen/Switzerland
Phone ++41 (0)61 926 50 00
Fax
++41 (0)61 926 50 50
www.ronda.ch
info@ronda.ch
1 . Werkdimensionen
Kaliber
Ø Total
Calibre
Ø Total
Caliber
Ø Total
Einh./ Unité/ Unit
mm
1005-1009
23,90
Stellwellengewinde/ Filetage de la tige/ Stem thread: Ø 0,90 mm
2 . Funktionen
Kaliber
Stellwellenpos.
Calibre
Pos. de tige
Caliber
Stem position
1
2
1006
3
1
2
1005, 1009
3
Technische Anleitung
Instructions techniques No. 318.0
Technical Instructions
1
10
/
1 .
Dimensions
des mouvements
Ø Werksitz
Werkhöhe
Ø Encageage
Hauteur mouvement Hauteur pile
Ø Case fitting
Movement height
mm
mm
23,30
1,90
2 .
Fonctions
Funktionen
Fonctions
Functions
Normale Position / Position normale / Running position
Datumkorrektur / Correction de la date / Date correction
Zeiger stellen, mit Unterbruch der Motorimpulse
Mise à l'heure, avec interruption des impulsions moteur
Hand setting, with interruption of the motor pulses
Normale Position / Position normale / Running position
Datumkorrektur / Correction de la date / Date correction
Zeiger stellen, Sekunden-Stopp mit Unterbruch der Motorimpulse
Mise à l'heure, stop-seconde avec interruption des impulsions moteur
'''
2
1005
Höhe Batterie
Height of battery
mm
1,90
Weg/ Chemin/ Length of travel: 1,00 mm
1006
1 .
Movement
dimensions
Höhe Stellwelle
Höhe Werkauflage
Hauteur tige
Hauteur filet
Height of stem
Movement rest
mm
mm
0,75
0,35
2 .
Functions
12
9
6
1009
1
2 3
3
23
