Bender ISOMETER isoNAV685-D Manual page 61

Modbus settings
Register
Register address
address
(hexadecimal)
(decimal)
//ModbusTCP Mode
0x3006u 12294
0x3007u 12295
//BCOM
0x300Au 12298
0x3012u 12306
0x3013u 12307
0x3014u 12308
0x3016u 12310
0x3019u 12313
0x301Bu 12315
//Time
0x3098u 12440
0x309Au 12442
0x309Cu 12444
0x309Eu 12446
0x309Fu 12447
0x30A1u 12449
61
Num-
Description Data type
ber
Modbus TCP on/off 2 Uint16
Writing to registers
2 Uint16
on/off
BCOM system name 16 String UTF 8
BCOM subsystem
2 Uint16
address
Device address 4 Float
Message timeout 4 Float
Repeat interval 2 Uint16
DNS server IP 4 Uint32
DNS domain 250 String UTF 8
Time 4 Unix Time
0 4 0
Time zone 4 Float
NTP on/off 2 Uint16
NTP server IP 4 Uint32
Date format 2 Uint16
Mode Comment
1 = Port 502 (ModbusTCP) on
R/W
2 = Port 502 (ModbusTCP) off
1 = Writing parameters on
R/W
2= Writing parameters off
R/W BCOM system name
R/W BCOM device address
R/W
R/W BCOM message timeout
Time interval in which a BCOM messages
R/W is sent from a device to the Gateway at
the latest
IP address of the DNS server
R/W aaa.bbb.ccc.ddd => aaa*256³
+ bbb*256² + ccc*256 + ddd
R/W DNS domain
R/W
R
R/W Time zone offset
1 = NTP on
R/W
0 = NTP 0ff
IP address of the NTP server
R/W aaa.bbb.ccc.ddd => aaa*256³
+ bbb*256² + ccc*256 + ddd
1 = d.m.y
R/W
2 = m.d.y
Range Unit
1...2
1...2
A-Z0-9_
1...255
1...255
0.1...10 s
0...65.535 s
0...
4.294.967.295
a-z0-9\.\-
-12...13 h
1...2
0...
4.294.967.295
1...2
