Baltimore Scroll-Back Chair
Assembly Instructions
603/0115
- Please keep for future reference
603/0122
Dimensions
Width - 46cm
Depth - 65cm
Height - 106cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 18/10/10
Advertisement
Related Manuals for Argos Baltimore 603/0115
Summary of Contents for Argos Baltimore 603/0115
- Page 1 Baltimore Scroll-Back Chair Assembly Instructions 603/0115 - Please keep for future reference 603/0122 Dimensions Width - 46cm Depth - 65cm Height - 106cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 18/10/10...
- Page 2 Safety and Care Advice Safety and Care Advice Important - Please read these instructions fully before starting assembly Important - Please read these instructions fully before starting assembly • At least 2 people are required • Discard all extra fittings and • We do not to assemble this product. keep fittings out of reach of recommend the children.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Backrest Seat Leg x 2 (106 x 39.5 x 14cm) (44.5 x 46 x 25cm) (44.5 x 5.5/4.4cm) Components - Fittings Please check you have all the fittings listed below... - Page 4 Assembly Instructions Assembly Instructions Assembly Instructions Step 1 Cloth cover Attaching the seat Place the backrest a flat protected surface. Position the seat the backrest shown. Align the holes and fix using bolts and washers . Tighten the bolts using allen key Important: Peel off bottom cloth cover of seat to be able to fix the bolts. Pull the cloth from the...
- Page 5 Wickham Scroll-Back Chair Assembly Instructions 603/0115 - Please keep for future reference 603/0122 Dimensions Width - 46cm Depth - 66cm Height - 105cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 3 - 03/12/13...
- Page 6 Safety and Care Advice Important - Please read these instructions fully before starting assembly • At least 2 people are required • Discard all extra fittings and • We do not to assemble this product. keep fittings out of reach of recommend the children.
- Page 7 Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Backrest Seat Leg x 2 (105 x 40 x 16cm) (46 x 42.5 x 23cm) (44 x 4 x 4cm) Components - Fittings Please check you have all the fittings listed below...
- Page 8 Assembly Instructions Assembly Instructions Step 1 Attaching legs Place the seat upside down on a flat protected surface. Insert the legs into the holes of the seat as shown and fix using bolts , spring washers and washers Important: Fasten bolts using allen key but do not fully tighten at this...
- Page 9 Assembly Instructions Step 3 Aligning & securing the legs Carefully turn the chair upright and place on a flat surface. Tighten all bolts using allen key Note: Use oval head of allen on tight angles. Note: This step is essential to prevent the chair from wobbling due to uneven legs.
- Page 10 Wickham Extendable Table Assembly Instructions 603/7462 - Please keep for future reference Dimensions Width - 150 (195)cm Depth - 90cm Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 9/02/10...
- Page 11 Assembly Instructions Safety and Care Advice Important – Please read these instructions fully before starting assembly Close table Unfold apron of leaves • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product during assembly, recommend the...
- Page 12 Components Parts If you have damaged or missing components, Assembly Instructions call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Open table Unfold apron of leaves Unlock Table top x 1 Step 1 Leg x 4 Step 2 Lock Step 3...
- Page 13 Assembly Instructions Components - Fittings Step 1 Please check you have all the fittings listed below Note :The quantities below are the correct amount to complete the assembly. In some cases more Place table top upside fittings may be supplied than are required. down being careful to not scratch the table top surface (Leaving the...
