Dining Chair
Assembly Instructions
Dimensions
Width - 45cm
Depth - 63.5cm
Height - 103cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
- Please keep for future reference
603/0263
603/0270
Issue 1 - 30/10/10
Advertisement
Related Manuals for Argos 603/0263
Summary of Contents for Argos 603/0263
- Page 1 Dining Chair Assembly Instructions 603/0263 - Please keep for future reference 603/0270 Dimensions Width - 45cm Depth - 63.5cm Height - 103cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the panels listed below Seat (45 x 44cm) Leg x 2 (44 x 2.5cm) Back Frame (103 x 40cm)
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. In some cases more Flat washer x 9 Bolt x 4 Bolt x 5 ( M8 x 90mm ) ( M8 x 50mm ) Spring washer x 9 Hex key x 1 Tools required Ruler - Use this ruler to help correctly identify the screws...
- Page 5 Replace the dust cover. Carefully turn the chair over and place it on the floor. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
- Page 6 Pair Of Dining Chairs Assembly Instructions 603/0270 - Please keep for future reference 603/0263 Dimensions Width - 45cm Depth - 63.5cm Height - 103cm Important – Please read these instru ctions ful ly before startin g assembl y If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 7 Safety and Care Adivce Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not the product during assembly, components and tools listed on recommend the this could cause damage.
- Page 8 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Seat Leg x 2 Back Frame (45 x 44cm) (44 x 4.5cm) (103 x 40cm)
- Page 9 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. In some cases more Flat washer x 9 Bolt x 4 Bolt x 5 ( M8 x 60mm ) ( M8 x 55mm ) Hex key x 1 Spring washer x 9 Tools required Ruler -...
- Page 10 Replace the dust cover . Carefully turn the chair over and place it on the floor. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
