The development board contains circuitry to support and present all the
features of the Z8 Encore! XP
Z8 Encore! XP Z8F642 MCU are:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
For more information on the Z8 Encore! XP family of devices, refer to
Z8 Encore! XP
for download at www.zilog.com.
F64XX Series Development Board
Z8 Encore! XP
TM
eZ8 core CPU
Up to 64 KB of Flash memory with in-circuit programming capability
Up to 4 KB of register RAM
Either eight or twelve channels, 10-bit ADC
Two Full-duplex UART
2
I C interface (Master Mode only)
Serial Peripheral Interface (SPI)
Infrared Data Association (IrDA)-compliant infrared encoder/decoder
Three or four 16-bit timers with capture, compare, and PWM
capability
Watchdog Timer (WDT) with internal RC oscillator
Thirty one, forty six or sixty I/O pins
Programmable priority interrupts
On-Chip Debugger (OCD)
Voltage Brownout Protection (VBO)
Power-on Reset (POR)
2.7 V to 3.6 V operating voltage with 5 V-tolerant inputs
Operating temperature: 20 °C ± 10 °C
®
F64XX Series Product Specification (PS0199) available
®
F64XX Series Development Kit
®
Z8F642. The main features of the
