24" HC SERIES, HB SERIES, & HD SERIES UNDERCOUNTER REFRIGERATION
Operation/Installation Manual

Refrigerant

Take caution when handling,
DANGER
moving and using the product to
avoid damaging the refrigerant tubing or increasing
the risk of a leak
All service work shall be
WARNING
performed by factory authorized
service personnel and all component parts shall be
replaced with like components to minimize the risk of
possible ignition due to incorrect parts or improper
service.
If service is necessary, repair work
CAUTION
must be performed by a Perlick
authorized servicer. Work done by unqualified
individuals could potentially be dangerous and will
void the warranty.

Preparing the Cabinet for Use

UNCRATING AND INSPECTION

Remove all crating material before operating. Carefully
inspect cabinet for hidden damage. If damage is
discovered, file your claim immediately with the
transport company. Perlick is not responsible for
damage in transit.
Do not use or store flammable
DANGER
liquids (ie; gasoline) or vapors
near the appliance to avoid fire.

INSTALLATION

The unit must NOT be totally
NOTICE
enclosed or damage may occur. Air
circulation must not be restricted. The condenser at
cabinet front must be provided with a minimum of two
inches air space. Be sure to provide access so front
cover can be removed to clean the condenser.
If unit has been laid on its back or
NOTICE
sides, place unit upright and allow
a minimum of 24 hours before connecting power.
Failure to follow this procedure may damage the
compressor and void the warranty.
Use care when handling, moving
NOTICE
and using the product to avoid
damaging the refrigerant tubing or increasing the risk
of a leak.
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
All models covered in this user manual are manufactured
using refrigerant R600a (Isobutane). R600a is a
hydrocarbon. This refrigerant is flammable and is only
allowed for use in appliances with fulfill the requirements
of UL471, or UL/IEC 60335-1 and UL/IEC 60335-2-89. (To
cover potential risk originated from the use of flammable
refrigerants). Consequently, R600a is only allowed to be
used in refrigerating appliances with are designed for this
refrigerant and fulfill the above-mentioned standard.
• R600a is heavier than air. The concentration will always
be highest at the floor level.
• The explosion limits are as follows:
o Lower Limit: 1.8% by volume
o Upper Limit: 8.4% by volume
o Ignition Temperature: 460°C

ELECTRICAL

For specifications, see data plate located on the
cabinet. Also, see wiring diagram located in this
publication.
Inspect the electrical cord and
WARNING
plug for damage prior to
energizing the unit to avoid potential electric shock.
Use electical grounding to avoid
WARNING
electrocution or electric shock.
This appliance is equipped with a 3-prong
(grounding) polarized plug for your protection
against possible shock hazards. Failure to use
grounding may result in death, serious injury, or
property damage.
Never use an extension cord to
WARNING
connect the unit to the electrical
source. Do not use a two-prong adapter or remove the
power cord ground prong. Failure to use grounding
may result in death, serious injury, or property
damage.
Using any voltage other than
NOTICE
specified will result in serious
damage to the unit.
