Summary of Contents for VMP LCD-CM2B
- Page 1 Instruction Sheet For: LCD-CM2B For more information, please contact us at: 345 Log Canoe Circle, Stevensville, Maryland 21666 Toll Free: 877.281.2169 Phone: 410.643.6390 Fax: 410.643.6615 www.videomount.com...
- Page 3 LCD-CM2B LCD-1CB). Thread the adjusting screws (#12 LCD-1CB and LCD-CM2B) into the threaded hole in the bottom of the pivot brackets LCD-CM2B and LCD-1CB) until the bottom of the screw is roughly even with the front of the pivot bracket.
- Page 4 Use either the M4 (#22 LCD-1CB and LCD-CM2B) or the M5 (#21 LCD-1CB and LCD-CM2B) screws as appropriate for your fl at panels to attach your fl at panels to the mounting plates LCD- 1CB and LCD-CM2B). Step 6 Through bolt the mounting plates...
