- Page 1 MONITOR REFERENCE SERIES o w n e r s m a n u a l...
-
Page 3: Table Of Contents
Monitor Reference series to life. Resplendent in a stunning black oak vinyl furniture finish and built with the accuracy that exemplifies the Monitor Audio brand world-wide, the six model strong Monitor Reference Series will look gorgeous in any room. -
Page 4: Positioning
The MR Centre should be positioned so that it is pointing at you, in your viewing position, and at approximate ear height. If it is below or above ear height, use some rubber feet (small feet supplied) to angle it slightly. Left Centre Right 0° 22° 30° 90° Surround Surround Left Right 110° 135° 150° Rear Rear Surround Left Surround Right Monitor Reference Series... -
Page 5: Channel Positioning
Spike Fixing The Monitor Reference Series floor standing loudspeakers, come with spikes. These enhance the acoustic performance of the loudspeaker and should be used where possible. The spikes can be found in the packaging of the MR4 and MR6 only. -
Page 6: Wiring Configurations
By bi-wiring/ bi-amping them you will get a cleaner, more smooth sound with tighter mid and more controlled bass. When bi-wiring these speakers, you must remove the terminal links. Failure to do so will result in damage to your amp. Monitor Reference Series... -
Page 7: Port Bungs
Port bungs WARNING: Care must be taken not to insert the port bungs too far into the port, as this may result in the foam bung being lost inside the cabinet. If the loudspeaker is to be installed in a small room, typically 9 sqM ( 80 sqFT), or a room known to reproduce accentuated bass response, it may be desirable to fit port bungs. -
Page 8: Amp Panel & Controls
12 Volt Trigger Input ~ Centre Pin = +12Vdc For external power control from AV amplifier/ receiver to the MRW10. Monitor Audio recommend using this function and a lead is supplied. A 12 volt signal is supplied by the AV amp/receiver and tells the MRW10 to turn on from standby mode. - Page 9 Volume Control This control allows the level or volume to be adjusted in order to achieve a balanced overall sound. To get the balanced sound a selection of familiar music or film excerpts will need to be played. Start with the volume at minimum and increase the level control until a balanced sound is established.
-
Page 10: Positioning & Initial Set Up Of Mrw-10
The Phase Control can now be set, please refer to page 7 for further information. It is important to try a variety of music and film excerpts with which you are familiar in order to obtain the optimum overall settings. Monitor Reference Series... -
Page 12: Trouble Shooting
Try adjusting the volume level of the source and try the switch in the ‘On’ position. If it still does not turn on/ power up, please contact your local dealer/ distributor or Monitor Audio immediately. - Page 14 Monitor Audio Ltd. 24 Brook Road Rayleigh, Essex SS6 7XJ England Tel: +44 (0)1268 740580 Fax: +44 (0)1268 740589 Email: info@monitoraudio.co.uk Web: www.monitoraudio.com Designed & Engineered in the United Kingdom Made In China Version 3. 2016...
