Instruction Manual
Page 1
S150
DRAFT

AIRSTREAM S150

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRSTREAM S150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Monitor Audio AIRSTREAM S150

  • Page 1   S150  Instruction Manual  DRAFT            Page 1 AIRSTREAM S150...
  • Page 2 Functionality ........................  5   3.2.3  Button Controls  .......................  5   4  Packaging ............................  5   4.1.1  Pack in accessories ......................  5   5  Specifications ..........................  6     This document is intended to be used as a reference for the supplier. It is designed to clearly  communicate all the key design features and reasoning behind the design supplied.   Note: This document contains confidential information that should not be distributed to third  parties without prior consent from the Monitor Audio board of Directors.                          Page 2 AIRSTREAM S150...
  • Page 3: Other Features

    Class D amplifiers   <1% THD+N (full power)  2.3 Other features  ARM Cortex M4    aptX codec for Bluetooth   3 Control 3.1 Local Controls Localised controls should include:   Volume up/down (side mounted)   Power on/standby (front mounted)   Auxiliary input button (side mounted)   Bluetooth source button‐ using BT logo. (side mounted)   Bluetooth pairing button (rear)  Localised inputs and connections should include:   3.5mm mini‐jack (aux input)   DC input by coaxial connector   USB type A connector for generic 5v charging purposes (Apple charging?) – removed Apple  authentication chip.      Page 3 AIRSTREAM S150...
  • Page 4 POWER ON/  STANDBY      VOLUME UP/DOWN BLUETOOTH SOURCE (BT  STD LOGO)  AUXILLIARY SOURCE  (AUX LOGO)     Figure 1. ‐ Airstream S150 Local Controls    DC INPUT  3.5MM   USB CHARGING  BT PAIRING  MINI‐JACK  (CONNECT LOGO  (CHARGE LOGO)  (AUX LOGO)  FROM A100)    Figure 2. ‐ Airstream S150 Inputs and Connections    Page 4 AIRSTREAM S150...
  • Page 5 3.2.2 Functionality  When the power button is pressed or the power lead is plugged in, the device will power on  and initialise.  The device will find and connect to the last BT paired device and then return  to whichever source was last selected (if available). The user can then scroll through the  available sources by pressing the source select button   Bluetooth should remain connected to the BT device, even when in Aux mode. When playing  a BT track and Aux is selected, the BT module should send a signal to the device to pause the  track.  3.2.3 Button Controls VOLUME  BLUETOOTH  SOURCE BUTTON  AUX SOURCE  BUTTON    Figure 3. – Side Button Controls   4 Packaging 4.1.1 Pack in accessories POWER   PSU adaptor + plug pins   Quick Start Guide  LED INDICATOR   Safety Instructions     Page 5 AIRSTREAM S150...
  • Page 6: Specifications

    13/16 Dimensions (each) (H x W x D) 274 x 120 x 137mm (10 ”) Charcoal Grey with Black Grille Cloth Colour/ Finish White with Light Grey Grille Cloth Weight (each) 2.25Kg (5lb 4oz)     Page 6 AIRSTREAM S150...
