Nauticam N85 Instruction Manual

Instruction Manual for N85 Ports
F
OREWORD
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, we pride ourselves in the ability to recognise the requirements
of professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high
level of user-friendliness by allowing stress-free installation and easy
operation of all important functions of the camera.
Each product is individually inspected and water pressure tested to ensure
optimum quality.
Please read this manual carefully before using the product, this will maximise
its performance as well as its lifetime.
W
ARRANTY
All NAUTICAM Products are warranted against any material and
manufacturing defects for two years from the date of purchase for consumer
use. This warranty only applies to products purchased from authorised
NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for service, please contact your regional authorized
service centre(s). Please note that this warranty only applies when the
product is purchased in the territory where the service centre is located.
NAUTICAM does not hold responsibility for damage, of any nature, to any
equipment used with and/or placed within our products.
NAUTICAM accepts no liability for any loss of captured images or the inability
to capture images even if it is due to the malfunctioning of our products.
Unauthorised modifications and/or repairs of our products will automatically
invalidate the warranty.
M P
OUNTING THE ORT
Remove the O-ring from the port, inspect for any damage and lightly coat it
with the provided lubricant before placing it back into its groove.
Verify that the port opening of the housing is clean and free from foreign
material.
Push the safety button of the port locking lever downwards.
Turn the port locking lever to the release position as shown.
Lift housing cap.
Align the Port mounting indices of the port and the housing.
Gently push the port into the port opening of the housing, until it cannot go in
any further.
