Tektronix IntelliFrame VX1410A Instruction Manual page 319

Replaceable Parts
Replaceable parts list
Fig. &
Tektronix part Serial no.
index
number effective
number
9–5
–0 020–2221–XX
–1 950–0991–00
–2 212–0157–00
–3 407–4524–00
–4 212–0671–00
–5 407–4525–00
–6 351–1010–00
–7 351–0800–00
–8 386–6999–00
9–14
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Serial no.
discont'd Qty Name & description
1R RACKMOUNT ASSEMBLY
1 COMPONENT KIT:RACKMOUNT KIT 1R,
(KIT CONTAINS ITEMS 1 THRU 8)
2 HANDLE ALUMINUM BLK
14 SCREW,MACHINE:8–32 X 0.5,FLH,100 DEG,STL CDPL,T–15
1 BRACKET:LEFT,RACKMOUNT,SILVER GRAY
4 SCREW,MACHINE:10–32 X 0.625,FLH,100 DEG,STL,CD PL,
TORX
1 BRACKET:RIGHT, RACKMOUNT,SILVER GRAY
1 GUIDE:RACK SLIDE EXTENSION BRACKET,CLOSED
SLOT,9.7 X 8.1 INCHES
1 GUIDE,SLIDE:CHASSIS TRACK, (PAIR)
1 PLATE,LEFT:OFFSET SPACER,16 X 1.45,0.062 THICK AL
VX1410A & VX1420A IntelliFrame Mainframe Instruction Manual
Mfr.
code Mfr. part number
80009 0202221XX
80009 950099100
0KB01 ORDER BY DESC
TK1943 407–4524–00
0KB01 ORDER BY DESC
TK1943 407–4525–00
06666 B–814–2
06666 CTS–124
TK1943 386–6999–00
