Specifications
4–4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 4–2: Secondary Power (Cont.)
Characteristic
Maximum DC Induced Ripple/Noise
Protection
Voltage Readout
Voltage Readout Accuracy, typical
Current Readout
VX1410A & VX1420A IntelliFrame Mainframe Instruction Manual
Description
Voltage Ripple/Noise
+24 V 150 mV
pp
+12 V 50 mV
pp
+5V 50 mV
pp
–2 V 50 mV
pp
–5.2 V 50 mV
pp
–12 V 50 mV
pp
–24 V 150 mV
pp
Over voltage protection
Under voltage protection
Over temperature protection
Short circuit protection
Readout of 24 V, 12 V, +5 V, –2 V, –5.2 V, +5 V
Standby if present, and +5V External via VXIbus or
RS232
3% maximum
Readout of the present current usage on the 24,
12 , +5, –2, and –5.2 V supplies with VXIbus or
RS232
