SYSTem Subsystem
COMMunicate DATE? ERRor?
SERial
VX1410A & VX1420A IntelliFrame Mainframe Instruction Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This section describes each command and query in the SYSTem subsystem. The
SYSTem subsystem controls the parameters shown in Figure 3–8. The SYSTem
subsystem collects the functions that are not related to the performance of the
IntelliFrame Mainframe.
SYSTem
FACTory
HELP IEMessage
MODel?
Figure 3–8: SYSTem subsystem hierarchy
Table 3–14 lists the factory default settings for the SYSTem:COMMunicate:Seri-
al parameters in the IntelliFrame Mainframe. These default settings do not
change when you issue the SYSTem:FACTory command.
Table 3–14: Default factory RS-232 communication settings
Command
SYSTem:COMMunicate:SERial[:RECeive]:BAUD
SYSTem:COMMunicate:SERial[:RECeive]:BITS
SYSTem:COMMunicate:SERial:CONTrol:RTS
SYSTem:COMMunicate:SERial:ECHO
SYSTem:COMMunicate:SERial:ERESponse
SYSTem:COMMunicate:SERial:LBUFfer
SYSTem:COMMunicate:SERial[:RECeive]:PACE
SYSTem:COMMunicate:SERial[:RECeive]:PARity[:TYPE]
SYSTem:COMMunicate:SERial[:RECeive]:SBITs
NVSave SYSReset TIME
NVRecall POWer
VERSion? OPTIons?
Factory default setting
9600
8
ON
1
1
1
XON
NONE
1
3–111
