Maintenance
Installing card guides
Slide the card guides toward the rear of
the mainframe; allow the front of the
card guide to snap into place.
Front
Removing card guides
Gently pull the card guide
forward until it pops out of place.
Figure 8–10: Removing the top and bottom card guides
8–14
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Rear
VX1410A & VX1420A IntelliFrame Mainframe Instruction Manual
