Classic Series Digital Clock/Timer Install Guide
OneVue Managed Time (Classic Series Models)
OneVue is a trademark of Primex. OneVue is an intelligent environmental monitoring and managed time solution. All other trademarks are the property of their respective owners.
Copyright ©2018 Primex. The Primex logo is a registered trademark of Primex. All Rights Reserved. 4/30/2018
Primex, Inc. | 965 Wells Street |Lake Geneva, WI 53147 | Phone:1-262-729-4853 | www.primexinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OneVue Classic Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Primex OneVue Classic Series

Summary of Contents for Primex OneVue Classic Series

  • Page 1 OneVue Managed Time (Classic Series Models) OneVue is a trademark of Primex. OneVue is an intelligent environmental monitoring and managed time solution. All other trademarks are the property of their respective owners. Copyright ©2018 Primex. The Primex logo is a registered trademark of Primex. All Rights Reserved. 4/30/2018...
  • Page 2 Primex. Ab o ut Pri m ex Primex is a leading provider of solutions that automate and maintain facility compliance, increase efficiencies, enhance safety and reduce risk for enterprise organizations in the healthcare, retail pharmacy, education, manufacturing and business vertical markets.
  • Page 3 Ab o ut thi s Gui d e Audience This guide is intended for users tasked with installing Digital Clocks/Timers for use with the Primex OneVue Managed Time (Classic Series Models) solution. Content messaging This guide includes notes, cautions, and warnings content that highlights important messages.

  • Page 4: Table Of Contents

    Specifications - Classic Series Dimension Specifications Digital code blue and elapsed timer operation Digital Clock/Timer Install - Classic Series Install Requirements Tilt Bracket and Wall Mount Dimensions - Classic Series Tilt Bracket Digital Clock/Timer Install - Classic Series Wall Mount Digital Clock/Timer Install - Classic Series Flush Mount Digital Clock/Timer Install - Classic Series Dual Sided Digital Clock/Timer Install - Classic Series Timer Control Switch Install...
  • Page 5 Im p o rtant Saf ety Instructi o ns READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT. Some of the following information may not apply to your particular product model; however, as with any electronic product, precautions should be observed during installation, operation, and maintenance. Installation must conform to state or local building codes and ordinances.
  • Page 6 Reg ul ato ry Ap p ro val s FCC Compliance Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Primex might cause harmful interference and void the FCC authorization to operate this product. FCC Radio Frequency Interference This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
  • Page 7 Note: This equipment marketed in the USA is restricted by firmware to only operation on 2.4G channel 1-11 Classic Series Digital Clock/Timer Install Guide...
  • Page 8 20 cm must be maintained between the antenna of this device and all person. The technical documentation relevant to the above equipment will be held at: Primex | 965 Wells Street | Lake Geneva, WI 53147 | Phone: (262) 729-4853 Company Representative: Mike O'Brien, General Manager...

  • Page 9: Specifications - Classic Series

    SPECIFICATIONS - CLASSIC SERIES Operation 12- or 24-hour time display PM indicator light Alternating time and date display option LED dimmer option (100%, 75%, 50%, 25%) Power outage memory backup for up to 8 hours Power Over Ethernet (PoE) PoE.IEEE 802.3af Compliant Certifications: FCC/IC/CE marked Actual power consumption: 12-Watts (Class 3) Environment...

  • Page 10: Dimension Specifications

    Di m ensi o n Sp eci f i cati o ns Classic Digital Clocks/Timer dimensions Clock Type Weight Max. Current Draw Height (A) Width (B) Depth (C) 2.5" (6.35 cm) 2.26 lbs. (1 kg) 230 mA 5.0" (12.7 cm) 10.75"...
  • Page 11 Mounted Dimensions Clock Type Width from Wall (A) Height from Ceiling (B) Depth of 2 Clocks (C) Dual 4” 21.0”(53.34 cm) 11.0” (27.94 cm) 7.5” (19.05 cm) 4-digit Dual 4” N/A* 11.0” (27.94 cm) 7.5” (19.05 cm) 6-digit *4” 6-digit clock is not available as wall mount. Classic Series Digital Clock/Timer Install Guide...

  • Page 12: Digital Code Blue And Elapsed Timer Operation

    Di g i tal co d e b l ue and el ap sed ti m er o p erati o n Capability of functioning as a normal clock and timer with both count-up and count-down options. When power is applied it begins operating as a digital clock.

  • Page 13: Digital Clock/Timer Install - Classic Series

    DIGITAL CLOCK /TIMER INSTALL - CLASSIC SERIES Learn how to install and operate a Classic Series Digital Clock/Timer.

  • Page 14: Install Requirements

    Commonly, a network is assigned to a clock during Your OneVue account ID and the settings provided during device preconfiguration are configured into your clocks and each clock is labeled before they are shipped from Primex. Power-over-Ethernet (PoE) digital clocks/timers Requires a connection to a PoE enabled LAN.

  • Page 15: Tilt Bracket And Wall Mount Dimensions - Classic Series

    Ti l t Bracket and Wal l Mo unt Di m ensi o ns - Cl assi c Seri es Dimension D - clock screw hole spacing. Dimension E - distance to wall surface for 4° mounting bracket Dimension F - distance to wall surface for 18°...

  • Page 16: Tilt Bracket Digital Clock/Timer Install - Classic Series

    Ti l t Bracket Di g i tal Cl o ck/Ti m er Instal l - Cl assi c Seri es Supplied parts (4) #10 Screw (4) Anchor (1) Bracket AC-powered installation requirements Hardwired (pigtial) installations require a 120V~ power line in a 4 in. x 4 in. junction box installed by a licensed electrician. The tilt bracket has a center pass-through hole for the 120V~ pigtail.

  • Page 18: Wall Mount Digital Clock/Timer Install - Classic Series

    Wal l Mo unt Di g i tal Cl o ck/Ti m er Instal l - Cl assi c Seri es Note: Most building codes prohibit the use of hardwired power connections for devices that can be removed without tools. Clock/timers mounted directly to a wall must have standard power plugs.

  • Page 19: Flush Mount Digital Clock/Timer Install - Classic Series

    Fl ush Mo unt Di g i tal Cl o ck/Ti m er Instal l - Cl assi c Seri es Supplied parts (2) Screw, #6 x 1 1/4” flat head (2) Anchor Required materials AC-powered models (not supplied) 1 standard 2x4 cut to 14.5 in. (36.8 cm) Digital clock model: 1 square shallow 4 x 4 (10.16 cm x 10.16 cm) junction box Digital timer model: 2 square shallow 4 x 4 (10.16 cm x 10.16 cm) junction boxes 4 drywall anchors...
  • Page 20 Mount the junction box(es) as specified below: Digital clock model - mount one junction box in the center of the opening and flush with the front side of the 2 x 4. Digital timer model - mount two junction boxes, each to be 1 in. (2.54 cm) from the center of the opening and flush with the front Classic Series Digital Clock/Timer Install Guide...
  • Page 21 side of the 2 x 4. Remove the clock face plate and set aside. Remove the four screws that secure the circuit board. Disconnect the circuit board power connector (A) and timer input connector (B).
  • Page 22 Route the AC power wire (A) through the back of the clock. For timer models only, route the timer input wires (B) through the back of the clock. Wire the AC-power. For timer models only, wire the timer input as specified below: Code blue timer input - wire to designated code blue system.
  • Page 23 Note: If the clock assembly does not line up with the junction box, it's possible to increase the opening up to 0.3 in. (14.7 in. total) on either side as well as 0.2 in.(5.6 in. total) on the top or bottom. If these adjustments still do not allow the clock assembly to be mounted to the junction box correctly, the junction box is required to be remounted Install drywall anchors to align with the four fastening holes located on the front of the clock assembly.

  • Page 24: Dual Sided Digital Clock/Timer Install - Classic Series

    Dual Si d ed Di g i tal Cl o ck/Ti m er Instal l - Cl assi c Seri es A Dual Sided Digital Clock/Timer consists of two single-sided clocks and a Dual Clock Bracket Kit. The kit includes a dual housing bracket, a flange that mounts to ceiling or wall, and the hardware necessary to complete the installation.
  • Page 25 Attach the bracket to the flange using the suppled shorter machine screws, nuts, and washers. Note: To wall-mount a 4 in. x 4 digit model, the bracket tabs are required to be on the bottom. For wall-mount only, knock out power cord break. Wire clocks to main power, using cord retaining clips to dress wires.

  • Page 26: Timer Control Switch Install

    Ti m er Co ntro l Sw i tch Instal l Digital Elapsed and Code Blue timers include a Timer Control Switch that is required to be mounted to a single-gang junction box (not supplied). The junction box dimension is typically 2.25 in. x 2.75 in. x 4 in. (5.72 cm x 6.99 cm x 10.16 cm). Step 1 - attach timer to timer control switch The timer control switch is not connected to the timer during shipment.
  • Page 27 How to clean a timer control switch The switch buttons and wall plate cover may be cleaned with water or a common disinfectant cleaning solution. Be sure to test any cleaning solutions on a small area of the switch before using it on the entire switch.

  • Page 28: Remove Digtial Clock/Timer From Tilt Bracket

    Rem o ve Di g ti al Cl o ck/Ti m er f ro m Ti l t Bracket How to remove a clock from a tilt bracket 2.5" model - from the top of the bracket using a screwdriver press each hook down to release the clock and pull out to unsnap bottom hinges.

  • Page 29: Remove From Dual-Mount Bracket

    Rem o ve f ro m Dual -Mo unt Bracket How to remove a digital clock/timer from a dual mount bracket 2.5” model - from the top of the bracket, using a screwdriver press each hook down to release the clock. Then pull out to unsnap bottom hinges.

  • Page 30: Manual Check-In

    Manual Check-In During each check-in, a digital clock/timer synchronizes its time with a NTP Server and transmits its status to your OneVue account. Also, any pending setting changes are downloaded to the clock and events of a code blue or elapsed timer are transmitted to your OneVue account.

  • Page 31: Warranty

    One Year Li m i ted Warranty Primex warrants this product to be free from defects in materials and workmanship for a standard of one (1) year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts.

  • Page 32: Technical Support

    Ensuring our customers experience excellent service is of utmost importance to Primex. Our network of Certified Sales and Service Partners offer technical support services for Primex products. If you have purchased Primex products or have a service agreement with a Primex Partner, they are your primary contact for all Technical Support inquires.
