Smart-Sync™ Personal Series LCD Clock Install
Guide
Smart-Sync™ Managed Time
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Primex, Inc. is under license. Other trademarks and trade names are
those of their respective owners.
OneVue is a trademark of Primex. OneVue is an intelligent environmental monitoring and managed time solution. All other trademarks are the property of their respective owners.
Copyright ©2018 Primex. The Primex logo is a registered trademark of Primex. All Rights Reserved. 10/17/2018
Primex, Inc. | 965 Wells Street |Lake Geneva, WI 53147 | Phone:1-262-729-4853 | www.primexinc.com
Advertisement
Table of Contents
Related Manuals for Primex Smart-Sync Personal Series
Summary of Contents for Primex Smart-Sync Personal Series
- Page 1 Smart-Sync™ Managed Time The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Primex, Inc. is under license. Other trademarks and trade names are those of their respective owners.
- Page 2 Primex. Ab o ut Pri m ex Primex is a leading provider of solutions that automate and maintain facility compliance, increase efficiencies, enhance safety and reduce risk for enterprise organizations in the healthcare, retail pharmacy, education, manufacturing and business vertical markets.
- Page 3 Ab o ut thi s Gui d e Audience This guide is intended for users tasked with installing Smart-Sync Personal Series LCD Clock for use with the Primex OneVue Managed Time solution. Content messaging This guide includes notes, cautions, and warnings content that highlights important messages.
- Page 4 Im p o rtant Saf ety Instructi o ns READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT. Some of the following information may not apply to your particular product model; however, as with any electronic product, precautions should be observed during installation, operation, and maintenance. Installation must conform to state or local building codes and ordinances.
- Page 5 Reg ul ato ry Ap p ro val s FCC Compliance Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Primex might cause harmful interference and void the FCC authorization to operate this product. FCC Radio Frequency Interference This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
- Page 6 Rad i o Stand ard s Sp eci f i cati o n (RSS) This device complies with Industry Canada licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 7 Euro p ean Uni o n Decl arati o n o f Co nf o rm i ty and Restri cti o ns Hereby, Primex Inc. declares that this equipment: Primex Synchronous Network System SNS4Z200 Personal Series LCD Clock complies with the essential requirements and other relevant provisions of Directive 1999/5/EC.
-
Page 8: Table Of Contents
Specifications - Smart-Sync Personal Series LCD Clock Add a Clock Mode Install Smart-Sync™ Personal Series LCD Clock Installation Requirements Installation and Operation Overview Wall Mount Tabletop Use Remove Clock from Clock-Lock Mount Battery Maintenance Warranty Technical Support... -
Page 9: Specifications - Smart-Sync Personal Series Lcd Clock
SPECIFICATIONS - SMART-SYNC PERSONAL SERIES LCD CLOCK Display operation Display settings and time zone are managed from OneVue Automatically adjusts for Daylight Saving Time (DST) Time mode setting: set to 12 hour or 24 hour Date format setting: set to Time & Date (month-day) or Time & Date (day-month), and option to show day of the week Dimensions Physical dimensions: 7.5 in. - Page 10 Backlight operation Switch on the side of the clock sets the backlight intensity to to High, Low, or Off. Set to High or Low: optical sensor on the top of the clock samples available light to determine whether to turn on the backlight. NOTE: Backlight use significantly reduces battery life.
- Page 11 Operational indicators Easy-to-read time, day of the week, and month-date display as well as two operational indicators. Icon Behavior Status Network Connection Solid Normal operation Indicator Display shows dashes and bars appear and Unit is powering up and a network connection has not disappear on lower icon been received Flashing...
-
Page 12: Add A Clock Mode
Ad d a Cl o ck Mo d e Upon first-power up at its installation location, a Smart-Sync Clock and Repeater enters Add a Clock mode as described below. Once powered on at its installation location, the device continuously searches for an available Smart-Sync Bluetooth Network. It may take up to 15 minutes for a device to authenticate and connect to an available Smart-Sync Bluetooth Network. -
Page 13: Install Smart-Sync™ Personal Series Lcd Clock
INSTALL SMART-SYNC™ PERSONAL SERIES LCD CLOCK Learn how to install and operate a Personal Series LCD Clock. -
Page 14: Installation Requirements
Instal l ati o n Req ui rem ents Refer to the Important Safety Instructions before installing, operating or performing maintenance of clocks. Installation location requirements 100 feet (30 meters) when in clear-line-of sight to another Smart-Sync device 50 feet (15.2 meters) when there is 1 internal wall between Smart-Sync devices 30 feet (9.1 meters) when there are 2 internal walls between Smart-Sync devices You can also measure the Bluetooth signal strength at an installation location... -
Page 15: Installation And Operation Overview
Instal l ati o n and Op erati o n Overvi ew Smart-Sync Clocks are designed to provide ease of installation, requiring no end user configuration, simply take-out-of the box and install. The only operation dependency is its connection to an available Smart-Sync Bluetooth Network. A Smart-Sync Clock is equipped with a Bluetooth Low Energy (BLE) Wireless Technology radio component, that allows the clock to establish a wireless connection to a Smart-Sync Bluetooth Network. - Page 16 In summary, from the time a Smart-Sync Clock or Repeater device is first powered on at its install location and connects to a Smart-Sync Bluetooth Network, it receives and sets its time within 15 minutes. If a Smart-Sync Bridge is in a 8-hour deployment mode, the device is added to your OneVue account within 30 minutes, and when not in a 8-hour deployment mode it may take up to 24 hours to 7 days.
- Page 17 Post-Installation Smart-Sync Clock Operation Once a Smart-Sync Clock has authenticated and connected to a Smart-Sync Bluetooth Network, the clock operates as described below. Once a day, at a system defined time, a Smart-Sync Bridge connects to your facility’s Ethernet or Wi-Fi network to receive UTC time from a NTP Server and check-in to OneVue to download Smart-Sync device setting updates.
-
Page 18: Wall Mount
Wal l Mo unt Depending on your security needs, you can choose among the two mounting options. How use the clock-lock mount for a secure, wall-mount installation The Clock-Lock feature is a specially designed hanger at the top center of the clock. The clock-lock is designed to prevent accidents if the clock is bumped and it may reduce theft by requiring a particular combination of moves to remove the clock. -
Page 19: Tabletop Use
Tab l eto p Use The Personal Series LCD Clock has an easel stand located on the back of the clock. How to set up the tabletop easel of a personal series clock Verify the installation requirements are met. For more information, see "Installation Requirements" on page 14. To place the clock on a table or desk, simply unfold both sides of the easel stand. -
Page 20: Remove Clock From Clock-Lock Mount
Rem o ve Cl o ck f ro m Cl o ck-Lo ck Mo unt To remove a Personal Series LCD Clock from a clock-lock mount, follow the steps illustrated below. Smart-Sync™ Personal Series LCD Clock Install Guide... -
Page 21: Battery Maintenance
Battery Mai ntenance The Personal Series LCD Clock indicates a low battery status by showing a low battery icon on the clock display. The battery condition is also transmitted to your OneVue account. During a low battery condition, the clock is set to a Warning state with a low battery status in your OneVue account. Battery use recommendations Use only high quality Alkaline batteries Always use fresh, superior-quality batteries, with an expiration date at least five years past the installation date. -
Page 22: Warranty
Primex retains the exclusive right to repair or replace the unit at its sole discretion. All merchandise returned must be shipped to Primex Attn: Returns Dept., N3211 County Road H, Lake Geneva, WI 53147. Primex retains the exclusive right to repair or replace the unit at its sole discretion. -
Page 23: Technical Support
Ensuring our customers experience excellent service is of utmost importance to Primex. Our network of Certified Sales and Service Partners offer technical support services for Primex products. If you have purchased Primex products or have a service agreement with a Primex Partner, they are your primary contact for all Technical Support inquires.
