Wi-Fi Analog Clock Install Guide
OneVue Managed Time
OneVue is a trademark of Primex. OneVue is an intelligent environmental monitoring and managed time solution. All other trademarks are the property of their respective owners.
Copyright ©2018 Primex. The Primex logo is a registered trademark of Primex. All Rights Reserved. 4/30/2018
Primex, Inc. | 965 Wells Street |Lake Geneva, WI 53147 | Phone:1-262-729-4853 | www.primexinc.com
Advertisement
Table of Contents
Related Manuals for Primex OneVue Wi-Fi Analog Clock Series
Summary of Contents for Primex OneVue Wi-Fi Analog Clock Series
- Page 1 OneVue Managed Time OneVue is a trademark of Primex. OneVue is an intelligent environmental monitoring and managed time solution. All other trademarks are the property of their respective owners. Copyright ©2018 Primex. The Primex logo is a registered trademark of Primex. All Rights Reserved. 4/30/2018...
- Page 2 Primex. Ab o ut Pri m ex Primex is a leading provider of solutions that automate and maintain facility compliance, increase efficiencies, enhance safety and reduce risk for enterprise organizations in the healthcare, retail pharmacy, education, manufacturing and business vertical markets.
- Page 3 Ab o ut thi s Gui d e Audience This guide is intended for users tasked with installing Analog Clocks for use with the Primex OneVue Synchronized Time solution. Content messaging This guide includes notes, cautions, and warnings content that highlights important messages.
-
Page 4: Table Of Contents
Specifications - Wi-Fi Analog Clocks Component Specifications Installation - First power up and setting its time Manual Check-In Install Analog Clocks Installation Requirements Battery Recommendations Wall Mount Install 12.5" Dual-Sided Battery-powered Analog Clock Install 12.5" Dual-Sided Electric-powered Analog Clock Install 16"... - Page 5 Im p o rtant Saf ety Instructi o ns READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT. Some of the following information may not apply to your particular product model; however, as with any electronic product, precautions should be observed during installation, operation, and maintenance. Installation must conform to state or local building codes and ordinances.
- Page 6 Reg ul ato ry Ap p ro val s FCC Compliance Pursuant to FCC 15.21 of the FCC rules, changes not expressly approved by Primex might cause harmful interference and void the FCC authorization to operate this product. FCC Radio Frequency Interference This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
- Page 7 Note: This equipment marketed in the USA is restricted by firmware to only operation on 2.4G channel 1-11 Wi-Fi Analog Clock Install Guide...
- Page 8 Euro p ean Uni o n Decl arati o n o f Co nf o rm i ty and Restri cti o ns Hereby, Primex Inc. declares that this equipment complies with the essential requirements and other relevant provisions of Directive...
-
Page 9: Specifications - Wi-Fi Analog Clocks
SPECIFICATIONS - WI-FI ANALOG CLOCK S Battery-powered models Typical four year battery life. Battery life is based on operating conditions and may vary due to installed site conditions Batteries required (not supplied) Electric (AC-powered) models Power Supply 100-240 VAC, 18 inch (45.72 cm) cord with plug Single-Sided: 67mA @ 120 VAC Dual-Sided: 134mA @ 120 VAC Network Communication Protocols... -
Page 10: Component Specifications
Co m p o nent Sp eci f i cati o ns The following images represent the back view of each clock model and its components. Analog clock battery-powered model components Analog clock electric-powered model components... -
Page 11: Installation - First Power Up And Setting Its Time
Instal l ati o n - Fi rst p o w er up and setti ng i ts ti m e Upon first power up at its installation location, a PoE Analog Clock initiates a connection to your facility's network. During each network connection, the clock obtains UTC time from an NTP Server and synchronizes obtained time to its Time Zone offset and DST rules, and check-ins to OneVue to transmits its status to your OneVue account and download any pending setting updates. -
Page 12: Manual Check-In
Manual Check-In During a check-in, a clock synchronizes its time with an NTP Server and transmits its status to your OneVue account. In addition, during each check-in any pending setting changes are downloaded to the clock. How to initiate a manual check-in for an analog clock Quickly press and release the button on the back of the clock to initiate a check-in. -
Page 13: Install Analog Clocks
INSTALL ANALOG CLOCK S Learn how to install and operate an Analog Clock. -
Page 14: Installation Requirements
. Your OneVue account ID and the settings provided during device preconfiguration are configured into your clocks and each clock is labeled before they are shipped from Primex. manual check-in For more information, see "Manual Check-In" on page 12. -
Page 15: Battery Recommendations
Battery Reco m m end ati o ns Battery use recommendations Battery life expectancy is based on common operating conditions and may vary due to installed site conditions and settings. Use only new high-quality name brand alkaline batteries Use batteries with expiration date five or more years beyond the installation date Use batteries with the same type and date code Do not use heavy duty and zinc carbon batteries as they will not last as long as high-quality name brand alkaline batteries Do not use rechargeable NiCad batteries, as their output voltage is too low to assure proper operation... -
Page 16: Wall Mount Install
Wal l Mo unt Instal l The backs of most Analog Clocks feature two specially designed Clock-Lock hangers spaced at precise distances, one on the top and the other on the bottom. The clock-lock feature prevents accidental removal if the clock is bumped and it may reduce theft by requiring a particular combination of moves to remove the clock. - Page 17 Slide the clock down over the screw heads to latch it into place. Clock is powered-on When the it automatically connects to your facility's network to connect to its NTP time source to synchronize see "Installation - First power up and setting its time" on page 11. its time and OneVue.
-
Page 18: Dual-Sided Battery-Powered Analog Clock Install
12.5" Dual -Si d ed Battery-p o w ered Anal o g Cl o ck Instal l A Dual-Sided Battery-powered Analog Clock consists of two single-sided analog clocks and a Dual Clock Kit. Using the kit you combine two clocks to create a dual sided clock, which can be either ceiling or wall mounted. Dual Clock Kit supplied parts (1) Dual mount bracket (1) Mounting plate... - Page 19 Slide the dual clock bracket over the four tabs on the mounting plate. A tap with a rubber mallet on the clock bracket may be required to set the clock bracket assembly fully into place. Examine the mounting plate to ensure the bracket is fully engaged. The small hole in top side of the mounting plate should be visible and fully exposed.
- Page 20 Place your hands at the 10/11 and 4/5 positions and turn the clock clockwise to lock into place. Clock is powered-on When the it automatically connects to your facility's network to connect to its NTP time source to synchronize its time and OneVue.
-
Page 21: Dual-Sided Electric-Powered Analog Clock Install
12.5" Dual -Si d ed El ectri c-p o w ered Anal o g Cl o ck Instal l A Dual-Sided Electric-powered Analog Clock consists of two single-sided analog clocks and a Dual Clock Kit. Using the kit you combine the two clocks to create a dual-sided clock, which can be either ceiling or wall mounted. Dual Clock Kit supplied parts (1) Dual mount bracket (1) Mounting plate... - Page 22 Step 2 - mount bracket kit to wall or ceiling Measure and drill holes into the wall or ceiling to align with the mounting plate hole spacing measurements. Attach the mounting plate to the wall or ceiling using the provided anchors and screws. Slide the assembled dual clock bracket over the four tabs on the mounting plate.
-
Page 23: 16" Dual-Sided Analog Clock Install
16" Dual -Si d ed Anal o g Cl o ck Instal l A 16" Dual-Sided Analog Clock consists of two analog clocks and a Dual Clock Kit. Using the kit you combine two clocks to create a dual-sided clock, which can be either ceiling or wall mounted. Dual Clock Kit supplied parts (1) Dual mount bracket (1) Mounting plate... - Page 24 Fasten a supplied #6 x 1/2" long screw to each mounting post located on the backside of each clock, leaving a 1/8 to 3/16 in. gap between the screw head and mounting post. Apply power to each clock. Battery powered model - insert batteries. Electric and PoE models - route cables through the bracket opening and complete connection.
- Page 25 For each clock - place clock into the bracket housing with the 10/11 and 4/5 numerals over the clock-lock tab and rotate clock clockwise to lock into place. The screws fastened to the clock mounting posts lock into the housing clock-lock tabs. Slide the assembled bracket over the four tabs on the mounting plate.
-
Page 26: Remove From Clock-Lock Mount
Rem o ve f ro m Cl o ck-Lo ck Mo unt Follow the illustrated steps below to remove an analog clock from a clock-lock mount. Wi-Fi Analog Clock Install Guide... -
Page 27: Remove Analog Clocks From A Dual Mount Bracket
Rem o ve Anal o g Cl o cks f ro m a Dual Mo unt Bracket This procedure is commonly performed to replace clock batteries. How to remove an analog clock from a dual bracket Place your hands at the 10/11 and 4/5 positions. Turn each clock counter clockwise to unlock the clock housing from the twist-lock mount. -
Page 28: Battery Maintenance
Battery Mai ntenance To manage and maintain battery-powered analog clocks, refer to information in this section. Low battery indication During each check-in, the clock's current battery level is transmitted to your OneVue account. Batteries should be replaced promptly upon reaching low battery status to maintain clock performance and reduce risk of battery leakage due to excess discharge. -
Page 29: Warranty
One Year Li m i ted Warranty Primex warrants this product to be free from defects in materials and workmanship for a standard of one (1) year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts. -
Page 30: Technical Support
Ensuring our customers experience excellent service is of utmost importance to Primex. Our network of Certified Sales and Service Partners offer technical support services for Primex products. If you have purchased Primex products or have a service agreement with a Primex Partner, they are your primary contact for all Technical Support inquires.
