A.9 ATX Power Connector (ATX1 and ATX2)
1
11
Table A-9:
ATX Power Connector
Pin Signal Pin Signal
1 +3.3V 11
2 +3.3V 12
3 GND 13
4 +5V 14 PSON#
5 GND 15
6 +5V 16
7 GND 17
8 FAL# 18
9 N/C 19
10 +12V 20
A.10 Fan Module Connector (FAN1 ~ FAN6)
1 3
Table A-10:
Fan Module Connectors
Pin Assignment
1 Fan speed
2 +12V
3 GND
A.11 Power Switch Connector (CN4)
Table A-11: Power Switch Connector
Pin Signal
1 #PS_ON
2 GND
10
20
+3.3V
-12V
GND
GND
GND
GND
N/C
+5V
+5V
