USING THE DEVICE

Install Battery
1. Remove the battery cover by pressing down at the arrow mark
and slide to the direction of the arrow as shown in the figures
below.
2. Install (2) AAA alkaline batteries and close the battery cover.
3. Remove the batteries if the thermometer is stored and not in
use.

MEASUREMENT MODES

The default measuring mode is for the adult forehead temperature.
Press the MODE button on the side of the thermometer to adjust
the measuring mode.
Adult Forehead Mode: measuring the forehead
temperature of adults
Children Forehead Mode: measuring the forehead
temperature of children (age: 3 ~ 36 months)
Object Surface Mode: measuring the surface
temperature of objects
EN-7
