ForaCare Suisse AG
Neugasse 55,
9000, St. Gallen,
Switzerland
www.foracare.ch
MedNet EC-REP GmbH
Borkstraβe 10, 48163 Mϋnster,
Germany
Forehead Thermometer
Stirnthermometer
Thermomètre frontal
Termometro frontale
Termómetro de frente
Voorhoofdthermometer
Termómetro de leitura na testa
Termometru de frunte
Operating Instructions
Bedienungsanleitung
Mode d'emploi
Istruzioni per l'uso
Instrucciones de funcionamiento
Gebruiksaanwijzing
Instruções de funcionamento
Instrucțiuni de utilizare
60°C
0123
-20°C
Ver 5.0 2021/08
311-1242100-038
FORA IR42a
85%
Advertisement
Table of Contents
Related Manuals for Fora FocusTemp
Summary of Contents for Fora FocusTemp
- Page 1 Termómetro de leitura na testa Termometru de frunte Operating Instructions Bedienungsanleitung Mode d’emploi Istruzioni per l’uso Instrucciones de funcionamiento Gebruiksaanwijzing Instruções de funcionamento Instrucțiuni de utilizare FORA IR42a ForaCare Suisse AG Neugasse 55, 9000, St. Gallen, Switzerland 60°C www.foracare.ch 0123 -20°C MedNet EC-REP GmbH Ver 5.0 2021/08...
- Page 2 EN-2...
- Page 3 2” Selecting the measuring unit / EN When the thermometer is off, press MODE key for 2 seconds to enter selection mode. Press MODE key again to switch between °F and °C. Press POWER key. Auswahl der Messeinheit / DE Wenn das Thermometer ausgeschaltet ist, drücken Sie 2 Sekunden lang die MODE-Taste, um in den Auswahlmodus zu gelangen.
-
Page 4: Intended Use
°F ile °C arasında değişiklik yapmak için tekrar MODE tuşuna basınız. POWER tuşuna basınız. INTRODUCTION Thank you for choosing FORA FocusTemp Forehead Thermometer. Please read this instruction manual first so that the thermometer can be used safely and correctly. Keep this instruction manual for future reference. -
Page 5: Lcd Screen
APPEARANCE AND KEY FUNCTIONS OF THE THERMOMETER 1. Probe lens 2. Display screen 3. Power/ Measure button 4. Protective sensor cap 5. Mode button 6. Memory button 7. Battery Cover LCD SCREEN 1. Adult body temperature indicator 2. Child body temperature indicator 3. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ THIS BEFORE USING AND KEEP THESE INSTRUCTIONS IN A SAFE PLACE Close supervision is necessary when the thermometer is used by, on, or near children, handicapped persons or invalids. Use the thermometer only for the intended use described in this manual. -
Page 7: Warning And Precautions
WARNING AND PRECAUTIONS ► As with any thermometer, proper technique is crucial to getting accurate temperature readings. Please read this manual thoroughly and carefully before use. ► Always operate the thermometer in an operating temperature range 10°C to 40°C, and relative humidity of less than 85%. -
Page 8: Using The Device
USING THE DEVICE Install Battery 1. Remove the battery cover by pressing down at the arrow mark and slide to the direction of the arrow as shown in the figures below. 2. Install (2) AAA alkaline batteries and close the battery cover. 3. - Page 9 MEASURING TEMPERATURE FOR ADULTS 1. Remove the protective cap. The forehead should be clear of hair and perspiration. 2. Aim at the center of the forehead area 3 to 7cm away from and perpendicular to the surface of the skin. 3.
- Page 10 WARNING AND PRECAUTIONS ► If the reading is < 31.9°C, “Lo” will be displayed. ► If the reading is ≥ 32.0°C and ≤ 37.9 °C, it will be displayed with a green backlight. ► If the reading is ≥ 38°C and ≥ 43°C, it will be displayed with a red backlight.
- Page 11 MEASURING TEMPERATURE FOR CHILDREN 1. Press the Power button to turn on the thermometer. 2. Press and hold the MODE button for 1 second before releasing. An adult facial profile should be flashing, indicating that the preset mode is for adults. 3.
-
Page 12: Measuring Surface Temperature
MEASURING SURFACE TEMPERATURE 1. Press the Power button to turn on the thermometer. 2. Press and hold the MODE button for 1 second before releasing. An adult facial profile should be flashing, indicating that the preset mode is for adults. 3. - Page 13 RECALLING PAST READINGS FORA FocusTemp stores 30 of the most recent readings. 1. Press and release the Power button to turn on the thermometer. 2. Press and hold the MEMORY button for 1 second to enter the memory mode which is indicated by a flashing "...
-
Page 14: About Normal Body Temperature & Fever
Please consult your physician if you are concerned about your body temperature readings. MAINTENANCE ● FORA FocusTemp has no user serviceable internal parts except for the battery replacement. ● Always replace the Sensor Cap (or place in cradle) when not in use. -
Page 15: Symbol Information
SYMBOL INFORMATION Symbol Referent Model number Consult instructions for use Caution, consult accompanying documents Temperature limitation Humidity limitation Keep away from sunlight Type BF Equipment Ingress protection rating Serial number CE Mark Manufacturer Disposal of waste equipment Medical device Authorised representative in the European Union EN-15... -
Page 16: Troubleshooting
TROUBLESHOOTING Message What it means What to do The ambient Only operate the temperature thermometer within an is outside of ambient temperature range the operating of 10°C to 40°C. temperature range. Review instructions and Measured repeat the measurement. temperature below Make sure the distance the measurement from the forehead is not... -
Page 17: Specifications
SPECIFICATIONS Model No.: FORA IR42a Dimension & Weight 155.46 (L) x 40.14 (W) x 39.45 (H) mm, 61.8g (without battery) Power Source 2 x 1.5V AAA alkaline batteries Battery Life With new batteries, approx. 5,000 measurements. Displayed Temperature • Forehead: 32°C to 43°C range •... -
Page 18: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS With respect to disposable products, ForaCare Suisse warrants to the original purchaser that, at time of delivery, each standard product manufactured by ForaCare Suisse shall be free from defects in material and workmanship and, when used for the purposes and indications described on the labeling, is fit for the purposes and indications described on the labeling. - Page 19 The FocusTemp is intended for use in an electromagnetic environment (for home healthcare and professional healthcare) in which radiated RF disturbances are controlled. The customer or the user of the FocusTemp can help prevent electromagnetic interference by maintaining a minimum distance...
- Page 20 Manufacturer’s declaration-electromagnetic emissions The FocusTemp is intended for use in the electromagnetic environment (for home healthcare and professional healthcare) specified below. The customer or the user of the FocusTemp should assure that it is used in such an environment. Emission test...
- Page 21 IEC healthcare 61000-4-11 Voltage Voltage environment. interruptions: interruptions: If the user of 0 % UT; 250/300 Not applicable the FocusTemp cycle requires continued operation during power mains interruptions, it is recommended that the FocusTemp be powered from an...
- Page 22 Manufacturer’s declaration-electromagnetic immunity The FocusTemp is intended for use in the electromagnetic environment (for home healthcare and professional healthcare) specified below. The customer or the user of the FocusTemp should assure that it is used in the environment specified below. Immunity...
- Page 23 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the FocusTemp is used exceeds the applicable RF compliance level above, the FocusTemp should be observed to verify normal operation.
- Page 24 Manufacturer’s declaration-electromagnetic immunity Test specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications equipment The FocusTemp is intended for use in the electromagnetic environment (for home healthcare and professional healthcare) specified below. Test Band Service Modulation Maximum Distance IMMUNITY Compliance...
