- Page 1 Thelin Hearth Products Parlour and Gnome Pellet Stove Maintenance Procedure...
- Page 2 Table of Contents Daily Maintenance Weekly Maintenance Monthly Maintenance Yearly Maintenance...
- Page 3 Parlour & Gnome Pellet Stove Daily Maintenance Step 1 STOVE MUST BE COMPLETELY COLD BEFORE PEROFORMING MAINTENANCE. Remove Firepot and thoroughly clean with a wire brush. Ensure holes are clear and are not obstructed by silica, clinkers or fly ash.
- Page 4 Parlour & Gnome Pellet Stove Weekly Maintenance Step 1 STOVE MUST BE COMPLETELY COLD BEFORE PEROFORMING MAINTENANCE. Open Front Door and remove left side Clean Out Cover. Step 2 Leave Front Door open so there is a one inch gap.
- Page 5 Parlour & Gnome Pellet Stove Weekly Maintenance Step 4 Connect the vinyl vacuum hose to your ash vacuum. If you ash vacuum does not have a fitting to accept the vinyl hose, use the vacuum adapter provided. Step 5 Thoroughly vacuum the left side heat exchanger compartment.
- Page 6 Parlour & Gnome Pellet Stove Weekly Maintenance Step 6 Remove the right side Clean Out Cover. Step 7 Leave Front Door open so there is a one inch gap. Step 8 Press the “Clean” button on the Switch Panel and let stove run for 30 seconds then push...
- Page 7 Parlour & Gnome Pellet Stove Weekly Maintenance Step 9 Thoroughly vacuum the right side heat exchanger compartment. Reinstall Clean Out cover when done. Step 10 Scrape Feed Chute with putty knife. Remove creosote, fly ash build up and accumulated sawdust.
- Page 8 Parlour & Gnome Pellet Stove Weekly Maintenance Step 12 Scrape inside of Firepot with putty knife to remove clinkers. Ensure holes are unobstructed. Step 13 Vacuum Feed Chute. Step 14 Vacuum Igniter hole.
- Page 9 Parlour & Gnome Pellet Stove Weekly Maintenance Step 15 Vacuum Firepot Holder compartment. Reinstall Firepot when done. Step 16 Vacuum left side of stove ash pockets next to Firepot. Step 17 Vacuum right side of stove ash pockets next to...
- Page 10 Parlour & Gnome Pellet Stove Weekly Maintenance Step 18 Vacuum Fan Guard. Fan Guard must be kept free of dust build up and lint. A blocked Fan Guard may cause stove to overheat, triggering the T1 Sensor and shutting the stove down.
- Page 11 Parlour & Gnome Pellet Stove Weekly Maintenance Step 21 Polish plated components as needed. Always clean gold plated parts only when the heater is cool. Step 22 Wipe Front Door glass. Step 23 Vacuum inside of Hopper as needed. Remove accumulated sawdust.
- Page 12 Parlour & Gnome Pellet Stove Monthly Maintenance Step 1 STOVE MUST BE COMPLETELY COLD AND UNPLUGGED BEFORE PEROFORMING MAINTENANCE. Check Clean Out Cap on Tee Connector on vent pipe. Step 2 Inspect the exhaust system frequently. Fly ash can accumulate in the vent pipe. Initial monitoring of the build-up in the vent pipe is necessary.
- Page 13 Parlour & Gnome Pellet Stove Yearly Maintenance Step 1 STOVE MUST BE COMPLETELY COLD AND UNPLUGGED BEFORE PEROFORMING MAINTENANCE. Have certified personnel inspect and clean venting as needed. Step 2 Have certified personnel clean combustion and exhaust fan assembly as needed.
