Thelin PROVIDENCE Owner's Manual

Insert
Hide thumbs Also See for PROVIDENCE:
Table of Contents

Advertisement

Quick Links

Download this manual
PROVIDENCE INSERT
Pellet Stove Owner's Manual
Installation and Operating Instructions
▪ STOVE MUST BE PROPERLY INSTALLED AND MAINTAINED OR A HOUSE FIRE MAY
RESULT.
▪ FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS.
▪ CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION AND PERMIT.
▪ FAILURE TO COMPLY WITH OWNER'S MANUAL INSTRUCTIONS AND INSTALLATION
GUIDELINES WILL VOID WARRANTY. SAVE THESE INSTRUCTIONS.
PLEASE LEAVE THIS MANUAL WITH THE OWNER!!
Please read this entire manual before installation and use of the pellet fuel-burning stove. Failure to follow these
instructions could result in property damage, bodily injury or even death.
SAFETY NOTICE
Made in the USA by:
Prov Ins Man Rev b 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROVIDENCE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thelin PROVIDENCE

Summary of Contents for Thelin PROVIDENCE

  • Page 1 PROVIDENCE INSERT Pellet Stove Owner's Manual Installation and Operating Instructions Made in the USA by: SAFETY NOTICE ▪ STOVE MUST BE PROPERLY INSTALLED AND MAINTAINED OR A HOUSE FIRE MAY RESULT. ▪ FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS. ▪ CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION AND PERMIT.
  • Page 2 PROVIDENCE INSERT PELLET STOVE INDEX OF CONTENTS Adjustable Hopper Assembly, 17 Laboratory Listing Label, 6 Battery Backup Operation, 23 Lighting Instructions, 21 Battery Indicator, 23 Maintenance Procedures, 24 Built-In Fireplace Clearances, 13 Masonry Fireplace Installation, 9 Built-In Side View, 14 & 15 Mobile Home Installation, 20 Built-In Venting, 14 &...

  • Page 3: Table Of Contents

    PROVIDENCE INSERT PELLET STOVE FIGURES Figure 1- Stove Dimensions Figure 2- Clearances Figure 3- Masonry & Zero Clearance Fireplace Venting Figure 4- Built-In Fireplace Clearances Figure 5- Built-In Venting Vertical Figure 6- Built-In Venting Horizontal Figure 7- Pipe Adapter & Hook-Up...
  • Page 4 You must WARNING maintain the designated airspace clearance around the chimney. This space around the chimney is THELIN HEARTH PRODUCTS DISCLAIMES necessary to allow heat to flow away from the RESPONSIBILITY FOR, chimney area. Insulation in this area will cause heat WARRANTY WILL BE VOIDED BY THE buildup, which could ignite wood framing.
  • Page 5 PROVIDENCE INSERT PELLET STOVE building code department before you begin your installation. Obtain a building permit in order to meet local building code requirements. Contact your local dealer if assistance is required before, during and after installation. Before Start-Up Check List 1.
  • Page 6 PROVIDENCE INSERT PELLET STOVE LABORATORY LISTING LABEL...
  • Page 7 Provide adequate clearances around air openings clean and free of ash buildup, lint, and dust. into the combustion chamber and provide adequate The Providence Insert has been designed and accessibility clearance for servicing and proper approved burning...

  • Page 8: Figure 1- Stove Dimensions

    PROVIDENCE INSERT PELLET STOVE FIGURE 1 – STOVE DIMENSIONS...
  • Page 9 PROVIDENCE INSERT PELLET STOVE VENT INFORMATION • Grade surface must be non-combustible material such as rock, dirt, gravel. Beware of plants, lawn, bushes, and shrubs, which are considered Install vent at clearances specified by vent combustible material. manufacturer. • Consult local building, fire or other official codes.
  • Page 10 Figure 2). fireplace if attached with mechanical fasteners. C. Make sure the Providence Insert will fit into your existing fireplace by measuring dimension Items can only be removed if they according to Figures 1 & 2. See Figure 8 for are mechanically fastened to the adjustable Hopper Assembly.
  • Page 11 A re-line is recommended and required in Canada. Venting must run as per Figures 3A-3D. D. Make sure the Providence Insert will fit into your existing fireplace by measuring dimension according to Figures 1 & 2. See Figure 8 for adjustable Hopper Assembly.

  • Page 12: Figure 2- Clearances

    PROVIDENCE INSERT PELLET STOVE FIGURE 2 – CLEARANCES Factory Built (Metal) and Masonry Fireplaces Minimum opening for Factory Built (Metal) and Masonry Fireplaces...
  • Page 13 PROVIDENCE INSERT PELLET STOVE FIGURES 3A-D – FACTORY BUILT (METAL) OR MASONRY FIREPLACE VENTING 3A- Vertical vent without outside air 3B- Vertical vent with outside air options...
  • Page 14 Note: Above installation examples are for reference. All installation must follow local codes and requirements. Additional Venting Your Thelin PROVIDENCE Insert is equipped with a blocked flue/high temp safety sensor that will shut the stove off if there is a down draft, blocked flue, or high temperature condition.

  • Page 15: Figure 4- Built-In Fireplace Clearances

    PROVIDENCE INSERT PELLET STOVE FIGURE 4 - BUILT-IN FIREPLACE CLEARANCES Illustrations reflect typical installations and are for design purposes and clearances. Actual installation may vary due to individual design preferences. Installed as Built-In (Wood or Metal Framing) Maintain clearance to combustibles on sides, back, and top of built-in as per Figure 4.
  • Page 16 Build hearth base with non-combustible hearth pad and secure to subfloor. Base should extent 6” in front and 6” to the sides of stove. Allow for the finished front material (i.e., tile, stone, slate) so that when the Providence is inserted into cavity, the front of the stove is flush with the finished material.
  • Page 17 Note: Above installation examples are for reference. All installation must follow local codes and requirements. Additional Venting Your Thelin PROVIDENCE Fireplace Insert is equipped with a blocked flue/high temp safety sensor that will shut the stove off if there is a down draft, blocked flue, or high temperature condition.
  • Page 18 PROVIDENCE INSERT PELLET STOVE FIGURE 7 – PIPE ADAPTOR & HOOK-UP 1. Silicone the top of flue flange with 500 degree HIGH-TEMP RTV silicone and insert flex liner or 4” pipe. Fasten pipe or flex liner with at least 3 sheet metal screws.

  • Page 19: Figure 8- Adjustable Hopper

    PROVIDENCE INSERT PELLET STOVE FIGURE 8– ADJUSTABLE HOPPER ASSEMBLY...

  • Page 20: Figure 9- Control Panel

    PROVIDENCE INSERT PELLET STOVE FIGURE 9 - CONTROL PANEL...

  • Page 21: Figure 10- Air Shutter

    PROVIDENCE INSERT PELLET STOVE COMBUSTION AIR ADJUSTMENT Combustion air can be adjusted by rotating the air shutter to close / open the air duct. Air adjustment is critical for proper combustion and stove efficiency. Adjust the shutter so the flame is bright yellow in appearance and is actively moving (not lazy). Dark flames, smoke or black tips on the flame is an indication of too little air.

  • Page 22: Figure 11- Surround Installation

    PROVIDENCE INSERT PELLET STOVE SURROUND INSTALLATION 1. To install the surround onto the stove engine, first make sure hopper flange assembly located on top of engine can move freely by loosening the four flange stud locknuts. Two in the front and two in the back.
  • Page 23 PROVIDENCE INSERT PELLET STOVE • Consult local building, fire or other official VENT INFORMATION codes. Local codes may be different and require Install vent at clearances specified by vent other clearances than shown here. manufacturer. MOBILE HOME INSTALLATION Secure first section of pipe to adaptor using three sheet metal screws.
  • Page 24 A wall thermostat or remote thermostat can be used Make sure power cord is connected both into stove to automatically control the Providence Insert. You (connector under control box on right side) and into will have the option of utilizing the thermostat to wall outlet.

  • Page 25: Figure 12- Control Functions

    You will have to burn the The CLEAN position is to be used only Providence for a few hours in order to determine the when the heater is not burning and has cooled down for maintenance and cleaning.
  • Page 26 Remember Battery Light Each feed position will fluctuate because the If you utilize the Thelin Hearth Products battery microprocessor automatically adjusts the feed and backup option, and the battery is plugged into the fan speed based on temperature. This means the...
  • Page 27 PELLET STOVE BATTERY BACKUP OPERATION WARNING The PROVIDENCE Fireplace Insert is equipped Make sure the red cable goes to the red terminal and the with battery backup technology. To utilize this black cable goes to the black terminal. If you hook these feature you will have to purchase the optional 12V up correctly the BATT light will glow green.
  • Page 28 MAINTENANCE and allow fan to run 30-45 seconds to blow excess ash out flue. The PROVIDENCE requires routine maintenance for maximum performance and prolonged life of 2. Glass cleaning- approximately every 1-2 parts and components, and it is mandatory for weeks warranty to remain in effect.
  • Page 29 PROVIDENCE INSERT PELLET STOVE b. Be extremely careful not to damage 4. Remove clean-out cover on bottom of the mica plates since they are very tee (outside, if applicable) and dump excess fragile. ash from tee. This should be checked every four to six weeks.
  • Page 30 PROVIDENCE INSERT PELLET STOVE i. Clean post exhaust fan duct with brush. Vacuum loosened ash. Duct can be cleaned by access through flue cleanout cover. See Figure 15. j. Reinstall fan motor assembly and apply high temperature silicone sealant around flange. Flange must...

  • Page 31: Figure 13-Clean-Out Covers

    PROVIDENCE INSERT PELLET STOVE FIGURE 13–CLEAN-OUT COVERS FIGURE 14 – CLEAN-OUT VENT PORT...

  • Page 32: Figure 15- Combustion Fan

    PROVIDENCE INSERT PELLET STOVE FIGURE 15 – COMBUSTION FAN...
  • Page 33 This usually takes 10 help you locate a potential problem in the event the minutes and, if the run temperature is not PROVIDENCE is not performing normally or as reached, then the stove shuts off. If this occurs, expected: simply relight the stove in order for the run 1.
  • Page 34 PROVIDENCE INSERT PELLET STOVE 5. Problem: Fan motor speed varies on its own. Sometimes it surges on its own. It will run on HI or CLEAN but not on LOW. Solution: Fan motor brushes are wearing out and need to be replaced. Contact your dealer or call factory for replacement brushes.

  • Page 35: Figure 16- Replacement Parts List

    PROVIDENCE INSERT PELLET STOVE FIGURE 16 – REPLACEMENT PARTS LIST Fan assembly Fan gasket Feed motor assembly Feed gasket Igniter T1 sensor T2 sensor Circuit board Switch board...

  • Page 36: Figure 17- Circuit Board Diagram

    PROVIDENCE INSERT PELLET STOVE FIGURE 17 – CIRCUIT BOARD DIAGRAM 17.0 Type 1 On/Off Thermostat Type 2 Low/High Thermostat...

  • Page 37: Figure 18- Electrical Schematic/ Wiring Diagram

    PROVIDENCE INSERT PELLET STOVE FIGURE 18 - ELECTRICAL SCHEMATIC/WIRING DIAGRAM...

  • Page 38: Figure 19- Igniter Location

    PROVIDENCE INSERT PELLET STOVE FIGURE 19 - IGNITER LOCATION Remove nuts Unscrews 1. The bracket holding the igniter is attached to the lid with two 10-32 nuts. The lid attaches to the air chamber with two 10-32 nuts. Also, a gasket (not shown), is installed between the lid and the air chamber.
  • Page 39 Thelin Hearth Products, Warranty Division, 63 Laxalt Dr. Carson City, NV 89706. Returned part or product will be repaired or replaced at Thelin Hearth Products option and will be returned to you freight prepaid as soon as practical, but not later than 30 days after receipt.
  • Page 40 PROVIDENCE INSERT PELLET STOVE THELIN HEARTH PRODUCTS 63 Laxalt Dr. Carson City, NV. 89706...
