Table of Contents
Welcome!
""""""""""""""
1
Unpacking
Controls and Functions 2
Controls and Functions - Cont'd 3
Controls and Functions - Cont'd
. . . ..
4
MC800 Indicator Unit - Controls. . . . . . . . . . . .. 5
Features 6
MC 800 Indicator Unit - Display. . . . . . . . . . . .. 7
Installation - Indicator Unit. . . . . . . . . . . . . . .. 8
Installation - Indicator Unit - 2 . . . . . . . . " . . . .. 9
Installation - Indicator Unit - 3 . . . . . . . . . . . . .. 10
Installation-ConnectingPower 11
Installation-Transducer-General 12
Installation-Transom Mount 13
Installation - Transom Mount. . . . . . . . . . . . . .. 14
Installation - Thru-Hull Mount. . . . . . . . . . . . .. 15
Installation - Wet Box Mount. . . . . . . . . . . . . .. 16
Installation-Direct Mount 17
Installation-Cabling 18
Operation 19
Basic Operation
Turning the Power on
Setting the Auto mode
Setting the Depth range
Setting the Zoom range
Setting the Sweep Speed
Operation-Continued 20
Setting the Gain
Silencing the Audio Alarms
Setting the Shallow Alarm
To silence the Shallow Alarm
Operation-Continued 21
Setting the Deep Alarm
To silence the Deep Alarm
Setting the Fish Alarm
To silence the Fish Alarm
Using the Flash Mode
Using the Display Freeze
Using the Backlight
Operation-Continued 22
Using the Simulator Mode
Digital Display Mode
