Omcan RS-CN-0271 Instruction Manual page 25

Model RS-CN-0571
Item No. Description
Rear Swivel Caster with Brake for
71042
ARC571Y
Swivel Front Caster without Brake for
79763
ARC571Y
68203 Base for ARC571Y
68225 Right Cover for ARC571Y
68226 Left Cover for ARC571Y
68268 Front Cover for ARC571Y
68168 Bottom LED for ARC571Y
68251 #4 LED Driver for ARC571Y
71046 Evaporator Insulation for ARC571Y
68269 Front Glass Fixer for ARC571Y
68270 After Air Vent Fixed Parts for ARC571Y
68271 Right Glass Fixer for ARC571Y
68272 Left Glass Fixer for ARC571Y
68172 Bottom Shelf Holder for ARC571Y
68176 Middle LED for ARC571Y
64750 #4 LED Transformer for ARC571Y
71052 Metal Price Tags for ARC571Y
68211 Left Bottom Shelf Holder for ARC571Y
68175 Right Top Shelf Holder for ARC571Y
68273 Bottom Glass Shelf for ARC571Y
71057 Metal Shelf Support for ARC571Y
68274 Left Top Shelf Holder for ARC571Y
68177 Left Top Shelf Holder for ARC571Y
68275 Middle/Top Glass Shelf for ARC571Y
44504
Position Item No. Description
1 68276 Right Top Shelf Holder for ARC571Y
2 71155 Left Side Glass for ARC571Y
3 64880 Right Side Glass for ARC571Y
4 68277 Front Glass for ARC571Y
5 68278 Top Glass for ARC571Y
6 68279 Top LED for ARC571Y
7-1 64751 #2 LED Transformer for ARC571Y
7-2 68280 Top Frame for ARC571Y
8 71153 Shelf Holder for ARC571Y
9 71164 Left Pole Cover for ARC571Y
10 68281 Middle Column for ARC571Y
11 68282 Bottom Frame for ARC571Y
12 71065 Right Pole for ARC571Y
13 68283 Middle Cover Plate for ARC571Y
14-1 71110 Door Handle for ARC571Y
14-2 71162 Left Door Frame for ARC571Y
15 71068 Top Upper Door Frame for ARC571Y
16 68244 Door Glass for ARC571Y
17 71113 Right Door Frame for ARC571Y
18 71071 Bottom Door Frame for ARC571Y
19 71114 Door Glide Wheel for ARC571Y
20 68284 Glass Strutting Piece for ARC571Y
21 68193 Air In/Outlet for ARC571Y
22, 24 71074 Bottom Black Glass Frame for ARC571Y
Parts Breakdown
Position Item No.
23 71121
25 71171
26 71077
27 71123
28 71079
29-1 71082
29-2 68196
30 71081
31 71126
32 71127
33 68285
34 71085
35 71087
36 71089
37 71133
38 71083
39 68220
40 68286
41 71136
42 68287
43 68199
44 68288
45
46
25
Description Position
Screw Cover for ARC571Y 47
Left Pole Fixer for ARC571Y 48
Pole Fixer (Right) for ARC571Y 49
Digital Control for ARC571Y 50
Thermostat Lid for ARC571Y 51
Thermostat Base for ARC571Y 52
Switch for ARC571Y 53
Evaporator Motor for ARC571Y 54
Evaporator Cover for ARC571Y 55
Evaporator for ARC571Y 56
Rear Frame for ARC571Y 57
Power Cord for ARC571Y 58
Back Grill for ARC571Y 59, 62
Water Tray for ARC571Y 60
Power Cord Fixer for ARC571Y 61
Dryer Filter for ARC571Y 63
Switch for ARC571Y 64
Condenser for ARC571Y 65
Fan Bracket for ARC571Y 66
Condenser Fan Motor for ARC571Y 67
Compressor for ARC571Y 68
Transformer for ARC571Y 69
