- Page 1 Refrigerated Showcases Models RS-CN-0120-5, 0160-5, 0202-5 Items 47107, 47278, 47279 Instruction Manual Revised - 09/15/2021 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model RS-CN-0120-5 / Model RS-CN-0160-5 / Model RS-CN-0202-5 Section Page Disclaimer -------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------- 5 - 7 Technical Specifications -------------------------------------------------------------------------- 8 Operation --------------------------------------------------------------------------------------- 8 - 10 Maintenance --------------------------------------------------------------------------------------- 10... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR... -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 5: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 6 Safety and Warranty Sufficient space Well ventilated The distance from both sides and back of refrigerator Always place the refrigerator in an area with proper to wall or other substance must be no less than 10 ventilation. When using for the first time, wait at least cm (4”).
- Page 7 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 8: Technical Specifications
Technical Specifications Model RS-CN-0120-5 RS-CN-0160-5 RS-CN-0202-5 Capacity 120 L / 4.2 cu.ft. 160 L / 5.65 cu.ft. 202 L / 7.13 cu.ft. 13.2” x 25” 13.2” x 32” 13.2” x 45.5” 335 x 636mm 335 x 813mm 335 x 1156mm Rack Size 14.4”... -
Page 9: Operation
Operation Digital Controller Operation: 1. Set Temperature: Press SET and the set temperature is displayed. Press button to modify and store the displayed value. Press SET to exit the adjustment and display the cold-room temperature. 2. If no buttons are pressed within 10 seconds, the cold-room temperature will be displayed. 3. -
Page 10: Maintenance
Operation CAUTION: Risk of fire. The height of the triangle in the symbol should be at least 15mm. Maintenance Keep the refrigerator clean and perform periodical maintenance as necessary. Always unplug the socket before maintenance. Never use a damaged plug or loose socket in order to prevent from electric shock or short circuit. -
Page 11: Troubleshooting
The refrigerator touches the wall or other objects. There is a loose part in the refrigerator. Contact Omcan at 1-800-465-0234 for help if simple troubleshooting does not solve the problems. The following situations are not problems: 1. The murmur of water is heard when the refrigerator is working. This is normal as the coolant is circulating in the system. -
Page 12: Parts Breakdown
Parts Breakdown Model RS-CN-0120-5 47107... - Page 13 Parts Breakdown Model RS-CN-0120-5 47107 Item No. Description Position Item No. Description Position Item No. Description Position AA062 Power Cord for 47107 79312 Nut Decoration for 47107 12-3 30759 Evaporator Protect Board for 47107 68510 Fixed Board of PCB Box for 47107...
- Page 14 Parts Breakdown Model RS-CN-0160-5 47278...
- Page 15 Parts Breakdown Model RS-CN-0160-5 47278 Item No. Description Position Item No. Description Position Item No. Description Position AA062 Power Cord for 47278 79312 Nut Decoration for 47278 12-3 AH735 Evaporator Protect Board for 47278 68510 Fixed Board of PCB Box for 47278 30624 Dry Filter for 47278 30805...
- Page 16 Parts Breakdown Model RS-CN-0202-5 47279...
- Page 17 Parts Breakdown Model RS-CN-0202-5 47279 Item No. Description Position Item No. Description Position Item No. Description Position AA068 Door Glass for 47279 60119 Switch for 47279 30751 Pillar for Bracket for 47279 AA069 Inner Door Frame for 47279 AH717 Left Panel for 47279 AH725 Left Seal for 47279 AA070...
-
Page 18: Electrical Schematics
Electrical Schematics Model RS-CN-0120-5 47107 Model RS-CN-0160-5 47278 Model RS-CN-0202-5 47279... -
Page 19: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 20 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
