Summary of Contents for Omcan RS-CN-0252-5
- Page 1 Refrigerated Showcase Model RS-CN-0252-5 Item 47424 Instruction Manual Revised - 08/24/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model RS-CN-0252-5 Section Page Disclaimer -------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------- 5 - 7 Technical Specifications -------------------------------------------------------------------------- 8 Operation ----------------------------------------------------------------------------------------- 8 - 9 Maintenance ----------------------------------------------------------------------------------------- 9 Troubleshooting ------------------------------------------------------------------------------- 9 - 10... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR... -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 5: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 6 Safety and Warranty SUFFICIENT SPACE The distance from both sides and back of refrigerator to wall or other substance must be less than 10cm. The refrigeration capability might be decreased if its surround space is too small to circulate air. GOOD VENTILATION Always place the refrigerator at a place with good ventilation.
- Page 7 1 YEARS PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
-
Page 8: Technical Specifications
Technical Specifications Model RS-CN-0252-5 Electrical 110V / 60Hz / 1 Power 460W Rated Current Capacity 252 L / 8.9 cu.ft. Shelf Capacity 55.1 lbs. / 25 kgs. 13.6” x 56.9” / 345 x 1444mm Rack Size 14.4” x 57.5” / 367 x 1461mm 12.6”... -
Page 9: Maintenance
Operation 4. Refrigerant LED: During refrigeration, the LED is on; when the cold room temp. is constant, the LED is off; During the delay start, the LED flashes. 5. Defrost LED: during defrosting, the LED is on; when it stops defrosting, the LED is off, during the delay display of defrost, the LED flashes. - Page 10 Regulate the temperature controller. Too noisy. The refrigerator is not level. The refrigerator is making contact with a wall or other matter. There is a loose part in the refrigerator. Contact Omcan for help if simple trouble shooting does not solve the problems.
-
Page 11: Parts Breakdown
Parts Breakdown Model RS-CN-0252-5 47424... - Page 12 Parts Breakdown Model RS-CN-0252-5 47424...
- Page 13 Parts Breakdown Model RS-CN-0252-5 47424 Item No. Description Position Item No. Description Position Item No. Description Position AK104 Door Glass for 47424 60119 Switch for 47424 AK120 Decorative Board for 47424 71639 Door Wheel for 47424 AH717 Left Panel for 47424...
-
Page 14: Electrical Schematics
Electrical Schematics Model RS-CN-0252-5 47424... -
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
