Omcan RS-CN-0271 Instruction Manual page 15

Model RS-CN-0271-S
Item No. Description
Rear Swivel Caster with Brake for
71042
ARC271Z
Swivel Front Castor without Brake for
79763
ARC271Z
68164 Right Cover for ARC271Z
68165 Base for ARC271Z
68166 Front Cover for ARC271Z
68167 Left Cover for ARC271Z
71046 Evaporator Insulation for ARC271Z
68168 Bottom LED for ARC271Z
68169 Front Glass Fixer for ARC271Z
68170 Right Glass Fixer for ARC271Z
68171 Left Glass Fixer for ARC271Z
68172 Bottom Shelf Holder for ARC271Z
68173 Metal Price Tags for ARC271Z
68174 Bottom Glass Shelf for ARC271Z
68175 Right Top Shelf Holder for ARC271Z
68176 Middle LED for ARC271Z
68177 Left Top Shelf Holder for ARC271Z
68178 Metal Shelf Support for ARC271Z
68179 Top Glass Shelf for ARC271Z
68200 Left Glass for ARC271Z
68201 Front Glass for ARC271Z
44382
Position Item No. Description
1 68202 Front Upper Beam for ARC271Z
2 68182 Top Glass for ARC271Z
3 68204 Top LED for ARC271Z
4 68184 Left Pole for ARC271Z
5 68185 Shelf Holder for ARC271Z
6 68205 Right Glass for ARC271Z
7 68187 Top Frame for ARC271Z
8 68188 Bottom Frame for ARC271Z
9 68189 Right Pole for ARC271Z
10 71110 Door Handle for ARC271Z
11 68190 Left Door Frame for ARC271Z
12, 14 71068 Top Upper Door Frame for ARC271Z
13 68191 Door Glass for ARC271Z
15 68192 Right Door Frame for ARC271Z
16 71071 Bottom Door Frame for ARC271Z
17 71114 Door Glide Wheel for ARC271Z
18 68193 Air In/Outlet for ARC271Z
19 71074 Bottom Black Glass Frame for ARC271Z
20 71121 Screw Cover for ARC271Z
21 68194 Pole Fixer Left for ARC271Z
22 68195 Pole Fixer Right for ARC271Z
Parts Breakdown
Position Item No.
23 71123
24 71079
25 71080
26 71081
27 71082
28 68197
29 71084
30 68198
31 71086
32 71087
33 64750
34 71089
35 71133
36 71083
37 77434
38 71135
39 71136
40 68199
41 71137
42
43
15
Description Position
Digital Control for ARC271Z 44
Thermostat Lid for ARC271Z 45
Switch for ARC271Z 46
Evaporator Motor for ARC271Z 47
Thermostat Base for ARC271Z 48
Evaporator Cover for ARC271Z 49
Evaporator for ARC271Z 50
Power Cord for ARC271Z 51
Rear Frame for ARC271Z 52
Back Grill for ARC271Z 53
#4 LED Transformer for ARC271Z 54
Water Tray for ARC271Z 55
Power Cord Fixer for ARC271Z 56
Dryer Filter for ARC271Z 57
Control Panel for ARC271Z 58
Condenser for ARC271Z 59
Fan Bracket for ARC271Z 60, 61
Compressor for ARC271Z 62
Condenser Motor for ARC271Z 63
