EXTRUDER FOR UNCAPPED HONEY
POWER SUPPLY 400V
Prior to device usage initiation, refer to the following manual
and act according the guidelines contained therein. The
manufacturer shall not be held accountable for any damages
caused by improper usage of the device or its improper
handling
.
1. GENERAL SAFETY OPERATING PRINCIPLES
FOR THE EXTRUDER FOR UNCAPPED HONEY

1.1. ELECTRICAL SAFETY

a) The device must be connected to a socket with the earthing
with the voltage specified on the nominal plate.
b) Power supply electric installation must be equipped with
RCD with nominal tripping current In below 30 mA.
Functioning of overcurrent circuit breaker must be checked
periodically.
c) Check the power supply cable periodically. If the non-
detachable power supply cable gets damaged and it must
be replaced, this will be performed by a guarantor or a
specialist service centre or a qualified person in order to
avoid any danger. Do not use the device when the power
supply cable is damaged .
d) In case of any damage to the device, in order to avoid any
danger, the repair must be performed by a qualified person
or a specialist service centre only .
e) It is forbidden to pull the power supply cable. The power
supply cable must be kept away from any heat sources,
sharp edges and its proper state must be secured.

1.2. OPERATIONAL SAFETY

a) The following equipment is not intended to be used by persons
with limited physical, sensory or mental capabilities (including
children) or persons inexperienced or unfamiliar with that type of
equipment unless the usage occurs under supervision or in line
with the equipment operating manual provided by safety
supervising persons.
b) The floor on which the device is placed must be dry!
c) The lattice protecting the hopper should be closed durian the
extruder operations!
d) Do not displace the extruder while in operation.
e) Protect the motor and the controller against humidity (also during
storage)
f) Do not operate the device in the vicinity of flammable materials.
g) It is forbidden to perform any maintenance works while the
device is under operation.
h) All shields must be fixed firmly while the device is under
operation.
i)
In case of any danger, use the emergency stop button
immediately.
The device restarting may occur once the danger has been
eliminated.
j)
The device may be activated indoors only. The device is not
adjusted for outdoor operation.
It is forbidden to make repairs while the device is in
operation
2.CHARACTERISTICS OF THE EXTRUDER
2.1. EXTRUDER FOR UNCAPPED HONEY
The device occurs in three efficiencies:
50, 100, 200 kg/h
The device is intended to separate the honey and press the
uncapped honey in a mechanical manner. This process occurs
inside a perforated cylinder, where a rotating separating and
pressing module presses the honey which gets through the
orifices between a separating shaft and perforated steel plate
and drains on a sieve located underneath. The remaining wax
is moved and pressed by a helix inside the extruder and moved
outside. In this manner we receive dry wax in the form ready to
be melted
2.2. DIAGRAM FOR THE EXTRUDER
1
4 3
2
5
