  • Page 3 Declaration of Conformity Declares under his sole responsibility that the produced Echo Sounder manufactured by Koden Electronics Co., Ltd. 5278 Uenohara Uenohara-Shi Yamanashi-Ken 409-0112, Japan Telephone +81 554 20 5860 Telefax +81 554 20 5875 CVS-702D Identified by the type number...
  • Page 5 Koden Electronics Co., Ltd. The technical descriptions contained in this publication are subject to change without notice. Koden assumes no responsibility for any errors, incidentals or consequential damages caused by misinterpretation of the descriptions contained in this publication.
  • Page 6  Koden is not liable for any damages caused by earthquake, lightning, wind and flood damage and fire for which Koden is not responsible, and actions by third parties, other accidents, customer’s unintended error/abuse and the use under other abnormal conditions.
  • Page 7 When the inside is to be checked, ensure to switch off the power and to discharge the residual voltage for safety. An engineer authorized by Koden shall carry out the inspection and maintenance works.
  • Page 8 In case of failure, please Warning contact Koden’s dealers or Koden. In case of smoking or firing, switch off the power in the boat and of this equipment. It may lead to firing, electric shock or damages.
  • Page 9 CVS-702D Contents Contents Document Revision History ....................... i Important Notice ........................ii For Your Safe Operation ......................iii Contents ........................... v Introduction ..........................vii Chapter 1 Preparation ....................1-1 1.1 To use keys ........................1-1 1.2 Power On/Off ........................1-3 1.2.1 Power On ..........................
  • Page 10 Contents CVS-702D 3.1.1 To use [CM] key for switching screen modes ..............3-2 3.1.2 To use [CM] keys as one touch switch to the memorized setting to the fishing positions .. 3-6 3.1.3 Use [CM] keys as screen mode switching and one touch switch of setting: ....3-10 Chapter 4 Useful operation ...................
  • Page 11 Introduction Introduction CVS-702D is an LCD color echo sounder that can display four individual images. This unit equipped with the latest digital process can accurately display circumstances in the water under all conditions, with a good match with the high brilliance 12.1 inch LCD.
  • Page 12 - This page intentionally left blank.-...
  • Page 13 VS-702D hapter 1 P Preparation Chapte er 1 Pre eparatio To use key y board of CVS-702D 15 16 Key Nam Descriptio [BRILL Press: P Power on. A Adjusts brillia ance of the screen and panel. Long-pr ress: Power off.
  • Page 14 Chapter 1 Preparati CVS-70 [← │←/NAV] Pres ss: Changes s the image scroll speed g-press: Dis splays the n avigation sc creen. VENT] Pres ss: Outputs the present position or the event cursor po osition in TL LL sentences s. Store ima age.
  • Page 15 VS-702D hapter 1 P Preparation Power On /Off .1 Power O ess the [BRI ILL ] key to p power on. e start-up s screen is d displayed. O On start-up p, the intern nal memory y (ROM an nd RAM) is omatically checked.
  • Page 16 Chapter 1 Preparati CVS-70 1.3 Select ion of lang guage to be e displayed When the power is sw witched on for the first t time after installation , the followi ing [Langua age] screen is d displayed. There are the other la anguages th han English...
  • Page 17 VS-702D hapter 1 P Preparation To use Me S-702D has s two kinds of menu, [M MENU] and [SUBMEN e operation of the both menus is b basically the e same. .1 Open/C Close the M Menu To d display the menu, pres ss the [MEN NU] key...
  • Page 18 Chapter 1 Preparati CVS-70 1.4.2 Ope eration of th he Menu Press [▲] key or [▼] key of to selec ct a menu it tem while M Menu is disp played. List of the s setting item ms changes to the corre esponding c contents wit th the selec...
  • Page 19 VS-702D hapter 1 P Preparation ess [ ] key o . ., a and the sett ting box app pears with th he correspo onding sele ction items. ess [▲] key or [▼] key to change t the setting. ess [ ] key r [SUBMEN NU] key .
  • Page 20 Chapter 1 Preparati CVS-70 1.4.3 pen/Close o of Submen To display the Subme enu, press th he [SUBME ENU] key List of Sub bmenu items s, operation n guide box x and functio on guide bo ox are displa ayed as sho below: Name of the sele...
  • Page 21 CVS-702D Chapter 1 Preparation 1.4.4 Operation of SUBMENU Press [▲] key or [▼] key of to select a menu item during SUBMENU is displayed. List of the setting items changes to the corresponding contents with the selected Submenu item. Menu column Setting item column...
  • Page 22 Chapter 1 Preparati CVS-70 Then, pres ss [ ] key o , an nd the settin ng box appe ears with th e correspon nding selec ction items. Press [▲] key or [▼] key of to chang ge the settin To return t the cursor to the set...
  • Page 23 CVS-702D Chapter 1 Preparation 1.5 To read echo sounder’s screen A screen of echo sounder consists of the header display in a gray color stripe at upper portion and the image display part of the echo sounder. The header display indicates setting status of various functions by icons for easier understanding.
  • Page 24 Chapter 1 Preparation CVS-702D Gain (TD) L2: Gain value of low frequency 2 L1: Gain value of low frequency 1 H2: Gain value of high frequency 2 H1: Gain value of high frequency 1 CM icons CM1 on display CM2 on display...
  • Page 25 CVS-702D Chapter 1 Preparation Display portion of echo sounder images Name Description Time marker indicates the image scroll speed. White/Black and Green/Black switch at every 5 minutes. : White/Black indicates 10 seconds. : Green/Black indicates 10 seconds. : White/Black indicates 1 minute.
  • Page 26 Chapter 1 Preparati CVS-70 1.6 Adjust tment of br rilliance for r comfortab ble viewing 1.6.1 Adju ustment of f LCD brillia ance The brillian nce of scree en can be a djusted with h [LCD Brill Each time [BRILL s pressed, [ [LCD Brill] a and [Panel...
  • Page 27 VS-702D hapter 1 P Preparation .2 Adjustm ment of pan nel brillianc e brilliance o of display p panel can be e adjusted a at [Panel Br rill] ch time [BR RILL ] key is p pressed, [LC CD Brill] and d [Panel Bri ll] are switc ched over.
  • Page 28 Chapter 1 Preparation CVS-702D - This page intentionally left blank.- 1-16 0093107022-02...
  • Page 29 Selection of changing method of gain 2.1.1 Display of 1-frequency/displays of 2-frequency and more CVS-702D can switch ON/OFF the display four individual images. To select Standard Echo Display: 1. Press [CM] key used ([CM] key lit red) When CM1 is lit red, press [CM1] key 2.
  • Page 30 Chapter 2 2 Basic op peration CVS- -702D 4. Pres s [ENT] key 5. Movi ing the cur rsor with , select t [Normal], [Mix] or [O OFF] in the e Standard Echo Displ lay items of f high freque ency 2, and d press [EN T] key...
  • Page 31 2.1.2 Setting frequency to match t the transdu ucer to be u used On C CVS-702D, the freque encies can n be set in n a range of (+/-) 10 % from the e specified frequ uency of the e transduce er.
  • Page 32 Chapter 2 2 Basic op peration CVS- -702D 6. Increas se or decrea ase the valu ue with [▲] and [▼] ke ey of to set freq quency. [▲] ke ey: The num meric value increases. [▼] ke ey: The num meric value d decreases.
  • Page 33 Setting up of frequency: Relation between a transceiver and display screen For CVS-702D, there are two types of transceiver for high frequency and low frequency, and each transceiver has two channels of channel 1 and channel 2. High frequency 1 is the channel 1 for high frequency.
  • Page 34 Chapter 2 2 Basic op peration CVS- -702D 2.1.3 Disp playing of z zoom imag To display zoom imag ges: 1. Press t the [CM] ke ey used (Lig hts red [CM M] key). When C CM1 is lit re ed, press th e [CM1] ke 2.
  • Page 35 CVS-702D Chapter 2 Basic operation Types of zoomed images 1. Bottom Normal images Zoom range Bottom images Sea bottom is fixed at 10% bottom of the screen, and the image above is displayed in the specified zoom range. As the image on sea bottom is magnified, this is an effective zooming mode to identify fish schools, etc.
  • Page 36 Chapter 2 Basic operation CVS-702D 2. Bottom discrimination Normal images Zoom range Bottom discrimination Sea bottom is fixed at 30% bottom of the screen, and the image of bottom is displayed in the specified zoom range. As the sea bottom image is magnified, this is an effective zoom mode to judge the sea bottom condition.
  • Page 37 S-702D Chapt ter 2 Basic c operation 3. Z Zoom Zoom rang ge bar Zoom m part ormal image es Zoom p part Norma al images Specifying a a shift posi tion, the im mages unde er the posit tion is disp played in th e specified zoom range...
  • Page 38 Chapter 2 Basic operation CVS-702D 4. Bottom zoom Bottom zoom Normal images Mixed images above bottom in a specified zoom range are displayed onto the normal image. This is an effective mode to identify fish schools, etc. near sea bottom with watching the geomorphic changes of sea bottom.
  • Page 39 S-702D Chapt ter 2 Basic c operation 5. B Bottom follow w zoom Zoom ran ge bar Botto es Bottom ormal image Norm al images follow w zoom follow zo In a specifie ed zoom ran nge, the se a bottom is displayed by automat tic shift to be...
  • Page 40 Chapter 2 2 Basic op peration CVS- -702D To change e the range e of zoome d images When the icon o show the e mode of [ Range] and d [Shift] key ys is in hea ader display y, the range of th he zoomed images can...
  • Page 41 S-702D Chapt ter 2 Basic c operation Scre een Width o of Zoom Im mage: screen wid dth of zoom med images s can be ch hanged to 3 3 steps of [Wide], [Me edium] and rrow] depen nding on pr eference.
  • Page 42 Chapter 2 2 Basic op peration CVS- -702D 4. [Disp. S Setup 1] of Menu is dis splayed. W With [▲] or [ [▼] keys of , po oint the curs sor to [Width o of Zoom Ima age]. Disp. Se etup1 dth of Zoom m Image...
  • Page 43 CVS-702D Chapter 2 Basic operation 2.1.4 Display of mixed images Mixed images are combination of high and low frequency images by signal processing. The main purpose is to identify small fish, such as whitebait, from other fish school. For example, when high frequency is 200 kHz, the wavelength of underwater acoustic wave is 0.75 cm, and when low frequency is 50 kHz, the wavelength of underwater acoustic wave is...
  • Page 44 Chapter 2 2 Basic op peration CVS- -702D To display y mixed im ages: 1. Press [C CM] key use ed (Lights re ed). When C CM1 is lit re d, press it 2. CM men nu is display yed. 3.
  • Page 45 S-702D Chapt ter 2 Basic c operation To ch hange the type of mix xed image: 1. Pr ress [MENU U] key 2. Th he menu is d displayed. M Move the cu ursor to [Dis sp. Setup1] with [▲] or r [▼] keys o 3.
  • Page 46 Chapter 2 2 Basic op peration CVS- -702D 5. Press [ ] key of 6. [Mix] of the menu i is displayed d. Move the e cursor to the desired d mix type w with [▲] an d [▼] keys of select.
  • Page 47 CVS-702D Chapter 2 Basic operation 2.1.5 Selection of pulse length Pulse length can be switched to 4 steps: of Short, Medium, Long and Fixed. This change of pulse length causes changes in resolution of images from the echo sounder and the signal to be displayed changes. Shorter pulse length increases resolution, but its power decreases.
  • Page 48 Chapter 2 2 Basic op peration CVS- -702D 4. Press [E ENT] key 5. Repeat t the procedu ures 3 and 4 4 above for r pulse lengt th of high fr requency 2, low freque ncy 1 and low w frequency 6.
  • Page 49 S-702D Chapt ter 2 Basic c operation 4. [M Manual Set] of menu is displayed. Move the c cursor at [P ulse Length h HF1] with h [▲] or [▼] eys of 5. Pr ress [ ] of 6. [P Pulse Lengt th HF1] of the menu...
  • Page 50 Chapter 2 Basic operation CVS-702D 2.1.6 Selection of frequency bandwidth Frequency bandwidth can be switched to 4 steps: Narrow, Medium, Wide and Fixed. The change of frequency bandwidth results in change of the resolution of echo sounder and change of signals in the displayed images. If the frequency bandwidth is wide, the resolution becomes high.
  • Page 51 S-702D Chapt ter 2 Basic c operation 4. Pr ress [ENT] k 5. Re epeat the pr rocedures 3 3 and 4 for f frequency b bandwidth o of high frequ uency 2, low w frequency and low fre equency 2 6.
  • Page 52 Chapter 2 2 Basic op peration CVS- -702D 4. [Manual Set] of the menu is dis splayed. Mo ove the curs sor to [Band dwidth HF 1 1] with [▲] o or [▼] keys of 5. Press [ ] of 6.
  • Page 53 S-702D Chapt ter 2 Basic c operation 2.1.7 7 Selection n of gain ad djustment method -702D can display fou ur individua al images a and gain ca an be adjus sted for ea ch images. Adjus stment of g gain is indiv vidually do ne with two...
  • Page 54 Chapter 2 2 Basic op peration CVS- -702D 2.2 Adjus stment of e echo sound To use ech ho sounder r, it is neces ssary to adj just depth r range (Ran ge) and ga ain dependin ng on the circum stances.
  • Page 55 CVS-702D Chapter 2 Basic operation When [Auto Range] is set, [Auto Range] is displayed in the header showing Range Mode. When [Manual] is set, display of the header showing the Range Mode disappears. When [Auto Shift] is set, [Auto Shift] is displayed in the header showing Range Mode.
  • Page 56 Chapter 2 2 Basic op peration CVS- -702D 2.2.2 Swit tching of N Normal/Zoo om for rang ge and shif ft operation The range key has tw wo functions s of “to chan nge range o of normal im mage” and “ “to change r range of zoomed...
  • Page 57 S-702D Chapt ter 2 Basic c operation 2.2.3 3 Manual c change of a a range for r normal im mage n Range m ode is Man ual, the ran nge can be c changed m anually. In m manual rang ge, each ti me range key is pre...
  • Page 58 Chapter 2 2 Basic op peration CVS- -702D Switching g the range operation to “Chang ge with [All Screens S Same]” or to o “Change e with [Scr. Indiv vidual]: 1. Press [M MENU] key 2. The men nu is displa yed.
  • Page 59 S-702D Chapt ter 2 Basic c operation 6. [R Range Opera ation] of me enu is displa ayed. Movin ng the curso or with [▲] o or [▼] keys s of elect [All Sc creens Sam e] or [Scr. I ndividual].
  • Page 60 Chapter 2 2 Basic op peration CVS- -702D To registe er ranges: 1. Press [M MENU] key 2. The men nu is displa yed. Move the cursor t to [Range S Setup] with [ [▲] or [▼] k keys of 3.
  • Page 61 S-702D Chapt ter 2 Basic c operation 6. [R Range1] of t the menu is s displayed . Set range e by increas sing or decr reasing num meric value with [▲] or [▼] keys of ・ The numeric va alue increas ses with [▲] ] key.
  • Page 62 Chapter 2 2 Basic op peration CVS- -702D T o change e ranges: 1. When th he header d display is , range of f normal ima ages can be e changed. If the he eader displa ay is press [NOR RMAL/ZOOM M] key to turn to...
  • Page 63 S-702D Chapt ter 2 Basic c operation To sw witch the o operation s screen for i individual r range: 1. A At the left b bottom cor ner of eac ch screen, nothing is shown, or r [Gain kno ob icon] of (red) or green) is dis...
  • Page 64 Chapter 2 2 Basic op peration CVS- -702D 2.2.4 Man nual chang e of shift p positions o of normal im mages When Ran nge Mode is s set at man nual, shift ca an be chang ged manua lly. In the man nual shift, t there are tw...
  • Page 65 S-702D Chapt ter 2 Basic c operation To sw witch shift t operation into “Cha nge with [A All Screens s Same]” o or “Change e with [Scr. Indiv vidual]”: 1. Pr ress [MENU U] key 2. Th he menu is d displayed.
  • Page 66 Chapter 2 2 Basic op peration CVS- -702D 6. [Shift Op peration] of the menu i s displayed d. Move the cursor with h [▲] or [▼] ] keys of and sel ect [All Scre eens Same e] or [Scr. In ndividual].
  • Page 67 S-702D Chapt ter 2 Basic c operation To s witch over r the shift o operation t type: 1. Pr ress [MENU U] key 2. Th he menu is d displayed. M Move the cu ursor to [Sh hift Setup] w with [▲] or [ ▼] keys of 3.
  • Page 68 Chapter 2 2 Basic op peration CVS- -702D 6. [Shift Ty ype] of the m menu is disp played. Mov ve the curso or with [▲] or [▼] keys s of and to s select one of [Numer rical Value] , [Range D Dependent], , [Preset V...
  • Page 69 S-702D Chapt ter 2 Basic c operation 3. Pr reset Value otal 8 shifts preset from m [Main Me enu], [Shift Setup], [Sh ift Preset1] ] to [Shift P reset8] can e switched e each time s shift key is p pressed.
  • Page 70 Chapter 2 2 Basic op peration CVS- -702D 4. [Range Setup] of th he menu is displayed. Move the c cursor to [Sh hift Preset1 ] with [▲] o or [▼] keys of 5. Press [ ] key of 6. [Shift P reset1] of t the menu is s displayed...
  • Page 71 S-702D Chapt ter 2 Basic c operation To c hange shif 1. W When the hea ader display y is , sh hift of norma al images ca an change. When the he ader displa y is press [NOR RMAL/ZOOM M] key to turn to 2.
  • Page 72 Chapter 2 2 Basic op peration CVS- -702D To switch ON/OFF of f shift: 1. Each tim me [SHIFT/M M OFF] key is pr ressed, the shift is swit tched on or off. The ic con showing g the shift co onditions in n header dis splay chang...
  • Page 73 S-702D Chapt ter 2 Basic c operation 2. To o turn [Gain n knob icon] ] to (red), pres ss [GAIN-L/ /SEL] for the left screen and GAIN-R/SEL for t the right scr reen until [G Gain knob ic con] turns s (red).
  • Page 74 In the synchronized gain, the gain of all screens change keeping the gain difference between screens. On CVS-702D, the gain of all screens including images in the past changes by operation of the gain knobs. Also, it can be switched to a mode in which only the gain of the current image changes, to watch changes by the gain operation.
  • Page 75 S-702D Chapt ter 2 Basic c operation 3. Pr ress [ENT] k 4. Pr ress [MENU U] key to close C CM menu. For a adjustment t of gain pe er screen ( (individuall ly):  In the case of f single freq quency scre een:...
  • Page 76 Chapter 2 2 Basic op peration CVS- -702D When [G GAIN-L/SEL or [ GAIN-R/SE re turned to right, the g increase es, and whe en turned to left, the ga in decrease  In the ca ase of 3 scr eens: Regardle ess of frequ...
  • Page 77 S-702D Chapt ter 2 Basic c operation  In the case of f 4 screens: egardless of f frequency , the gain o of two left sc creens (Low w frequency y 2/Low freq quency 1) is erated with h [GAIN-L/S SEL] and the ga ain of two...
  • Page 78 Chapter 2 2 Basic op peration CVS- -702D To adjust the gain: The gain c can be adjus sted on the screens on n which [Ga in knob icon n] of (red) or green) is dis splayed at t he lower lef When gain n knob is no ot displayed...
  • Page 79 S-702D Chapt ter 2 Basic c operation For g gain adjust tment of al l screens a at the same e time (syn nchronized 1. At CM1, pres s [CM1] key ights red [C CM] key). 2. CM M menu is d displayed.
  • Page 80 Chapter 2 2 Basic op peration CVS- -702D For gain a adjustment t of all scre eens at sam me time (sy ynchronize 1. If [GAIN N-L/SEL] or [GA AIN-R/SEL] is tu urned, the [ [Synchroniz zed Gain] b box is displaye This [Sy ynchronized...
  • Page 81 S-702D Chapt ter 2 Basic c operation Type es of gain c change: Ther re are two t ypes of gai n change w when gain a adjustment is done wit th a gain kn nob. One is that t the gain of all screens including im...
  • Page 82 Chapter 2 2 Basic op peration CVS- -702D 4. [System m] of the SU UBMENU is s displayed. . Move the cursor to [ Gain Type] with [▲] o or [▼] keys of 5. Press [ ] key of 6. [Gain T Type] of the e SUBMEN NU is displa...
  • Page 83 S-702D Chapt ter 2 Basic c operation 2.2.6 6 Adjustme ent of TVG reflected s ignals of ec cho sounde er have les s sensitivity y due to att ttenuation, a as depth is deep per. This means tha at the same e fish scho ools at shal lower posit...
  • Page 84 Chapter 2 2 Basic op peration CVS- -702D 4. [TVG] o of the men u is display yed. Move the cursor to [TVG T Type] with [ [▲] or [▼] keys 5. Press [ ] of 6. [TVG Ty ype] of the m menu is disp played.
  • Page 85 S-702D Chapt ter 2 Basic c operation To ad djust with manual TV ere are two ways of TV VG adjustm ment: to adju ust in the m main menu a and to assig gn [F1]/[F2] keys to adjust b y the functi on keys.
  • Page 86 Chapter 2 2 Basic op peration CVS- -702D 4. [TVG] o of the menu u is displaye ed. Move th he cursor to o [TVG Stre ength HF1] ] with [▲] o or [▼] keys of 5. Press [ ] key of 6.
  • Page 87 S-702D Chapt ter 2 Basic c operation 11. P Press [SUBM MENU] key to r return to [TV VG]. 12. P Point the cu rsor to [TVG G Adjust HF F1] with [▲] ] or [▼] key ys of 13. P Press [ ] ke ey of 14.
  • Page 88 Chapter 2 2 Basic op peration CVS- -702D To manua lly adjust T TVG with [F F1]/[F2] key 1. At first, a assign [MEN NU] key or [F2] ] key with [TVG]. As for th he setting m method of [F F1]/[F2] keys s, see “4.2.2 2 Assign int...
  • Page 89 S-702D Chapt ter 2 Basic c operation 7. In the case o of [TVG De epth HF1], set [TVG D Depth HF1] by increas sing or decr reasing the umeric valu e with [▲] o or [▼] keys With [▲] k key, the valu ue increase With [▼] k...
  • Page 90 The reflected signals of echo sounder have less sensitivity due to attenuation, as depth is deeper. In the TVG correction for CVS-702D, a reference point of depth for correction is to be determined. This reference point is [TVG Depth]. Reflected signals from a shallower depth than this reference point are corrected to have the same sensitivity as that of the reference point.
  • Page 91 CVS-702D Chapter 2 Basic operation Adjustment of TVG Depth of manual Adjustment of TVG Adjust (start point) of manual TVG [TVG Depth] is the reference point of depth [TVG Adjust] adjusts excessive for correction. The deeper the setup correction by TVG against shallow signals,...
  • Page 92 Chapter 2 Basic operation CVS-702D To use of optimized TVG:  Optimized TVG corrects the reflected signal from shallower than the [Depth] where color is produced with maximum level. This is done by having room for gain adjustment, in reference to the diffusional attenuation and absorption attenuation of ultrasonic sound.
  • Page 93 S-702D Chapt ter 2 Basic c operation To ad djust TVG Adjust in m main menu 1. Pr ress [MENU U] key 2. Th he menu is d displayed. M Move the cu ursor to [TV VG] with [▲] ] or [▼] key ys of 3.
  • Page 94 Chapter 2 2 Basic op peration CVS- -702D 6. [TVG A Adjust HF1] of the me enu is displ layed. Set [TVG Adju st HF1] by y increasing g and decreasi ing the num meric value w with [▲] or [▼] keys of th [▲] key, t the value in...
  • Page 95 S-702D Chapt ter 2 Basic c operation 5. Ad djust the nu meric value e with [▲] o r [▼] keys o o set [TVG A Adjust HF1] With [▲] k key, the valu ue increase With [▼] k key, the valu ue decrease 6.
  • Page 96 Chapter 2 Basic operation CVS-702D 2.3 Changing of the image scroll speed The image scroll speed can be changed at 13 steps of [Speed -2], [Speed -1], • • • [Stop], [Speed 2], • • • [Speed 9]. The larger the speed number is, the slower the image scroll speed becomes.
  • Page 97 CVS-702D Chapter 2 Basic operation To stop image scroll: 1. While [Image Speed] adjustment box is displayed, move the cursor to [Stop] with [▲ ] key When the cursor is at [Speed 2 (1/1)], press [Image speed] key , and the cursor moves to [Stop].
  • Page 98 Chapter 2 Basic operation CVS-702D 2.4 Finding out depth of targets in images (VRM operation) VRM (Variable Range Marker) is a mobile marker to measure the depth of targets such as fish schools, and indicates lines and depth values of the lines.
  • Page 99 S-702D Chapt ter 2 Basic c operation <Exa ample of dis splay of VR M whole sc creen (Scree en individua al range)> VRM 1 line VRM 2 2 lines 2.4.1 1 Changing g of VRM f ollow inter rval Unde er the first VRM, anot...
  • Page 100 Chapter 2 2 Basic op peration CVS- -702D 4. The me nu [Disp. s etup 2] is d displayed. M Move the cu ursor to [VR RM Interval] ] with [▲] o or [▼] keys o 5. Press [ ] key of 6.
  • Page 101 S-702D Chapt ter 2 Basic c operation 2.4.2 2 Operatio on of VRM i n Active Sc creen To sw witch VRM M display to o Active Sc creen: 1. Pr ress [MENU U] key 2. Th he menu is d displayed.
  • Page 102 Chapter 2 2 Basic op peration CVS- -702D 6. The men nu [VRM Im mage] is dis played. Mov ve the curs sor with [▲] or [▼] keys s of , and select [A Active Scre en] and [All l Screens]. 7.
  • Page 103 S-702D Chapt ter 2 Basic c operation 2.4.3 3 Operatio on of VRM o on all Scree To sw witch over r VRM Imag ge to All Sc creens: 1. Pr ress [MENU U] key 2. Th he menu is d displayed.
  • Page 104 Chapter 2 2 Basic op peration CVS- -702D 6. The me enu [VRM Im mage] is dis splayed. Se elect [Active e Screen] [A All Screens s] by movin ng the cursor w with [▲] or [▼] keys of 7. Press [M MENU] key , an d the menu...
  • Page 105 2. Blur due to micro animate beings such as plankton 3. Noise caused by electric signal synchronized with transceiver CVS-702D is equipped with functions to weaken the effect by each cause. 2.5.1 To reject interference Interference is generated by the reception of signals transmitted by other echo sounders.
  • Page 106 Chapter 2 2 Basic op peration CVS- -702D To setup [ [IR] (Interfe erence Reje ection) fun ction and t to eliminat e interferen nce wave: There are 3 steps of s setting: [OF F], [Low] an nd [High] fo r interferen ce rejection n function.
  • Page 107 S-702D Chapt ter 2 Basic c operation 6. Th he menu [IR R] is display ed. Select [ [Low] with [ ▲] or [▼] o 7. By y viewing im mages, conf firm that inte erference h as disappea ared. 8.
  • Page 108 Chapter 2 Basic operation CVS-702D 2.5.2 To erase the weak response from dust and plankton, etc. To erase the weak response from dust and microbes such as plankton in seawater, there are following 4 methods: 1. Setting TVG 2. Shortening pulse length and narrowing frequency bandwidth 3.
  • Page 109 S-702D Chapt ter 2 Basic c operation To se et [Color E Erase]: 1. Pr ress [MENU U] key 2. Th he menu is d displayed. M Move the cu ursor to [Ec cho Adjust] w with [▲] or [▼] of 3.
  • Page 110 Chapter 2 2 Basic op peration CVS- -702D 6. The men nu of [Color r Erase] is d displayed. A Adjust [%] w with [▲] or [ ▼] keys of With [▲] key, [% %] increases s (Bluish co olor first disa appears firs st).
  • Page 111 Chapter 2 Basic operation 2.5.3 To reduce noise CVS-702D is equipped with the [Noise Reduction] function. For [Noise Reduction] function, by narrowing the dynamic range and reducing tone graduation of colors, the color of weak response level becomes less visible.
  • Page 112 Chapter 2 2 Basic op peration CVS- -702D To set [No oise Reduc ction]: 1. Press [M MENU] key 2. The men nu is displa yed. Move the cursor t to [Echo Ad just] with [▲ ▲] or [▼] ke eys of 3.
  • Page 113 S-702D Chapt ter 2 Basic c operation 6. Th he menu [No oise Reduc ction] is disp played. Adju ust the value e with [▲] o or [▼] keys With [▲] k key, the valu ue increase With [▼] k key, the valu ue decrease The bigger t...
  • Page 114 - This page intentionally left blank.-...
  • Page 115 CVS-702D is equipped with six [CM] keys, so can be used as if six units of echo sounders were used at a time.
  • Page 116 [CM] keys CVS- 702D 3.1.1 To u use [CM] ke ey for switc ching scre en modes CVS-702D D is not equ ipped with t the switchin ng knobs or r dedicated keys for sc creen mode es like...
  • Page 117 S-702D Chapter 3 To make th he best of [CM] keys To se et [CM] key y to [Scree n mode sw witching]: 1. Pr ress [SUBM MENU] key 2. Th he SUBMEN NU is displa ayed. Move the cursor to [System] ] with [▲] or r [▼] keys o...
  • Page 118 Chapter 3 3 To make the best of f [CM] keys CVS- 702D 5. Press [ ] of 6. The SU BMENU [C M Key Usa age] is displ ayed. Move e the cursor r to [Screen n Mode] wit h [▲] or [▼] k keys of...
  • Page 119 S-702D Chapter 3 To make th he best of [CM] keys 6. Fo or selection n of Standa ard Echo D Display of h high freque ncy 2, low frequency 1 and low frequ uency 2, rep peat the pro ocedures 4 a and 5.
  • Page 120 Chapter 3 3 To make the best of f [CM] keys CVS- 702D 3.1.2 To u use [CM] k keys as on ne touch sw witch to th he memoriz zed setting g to the fis shing itions When one of the CM1 1 to CM6 ke eys (CM ke...
  • Page 121 S-702D Chapter 3 To make th he best of [CM] keys To se et [CM] key y to [One to ouch switc ch of settin g] : 1. Pr ress [SUBM MENU] key 2. Th he SUBMEN NU is displa ayed.
  • Page 122 Chapter 3 3 To make the best of f [CM] keys CVS- 702D 5. Press [ ] of 6. The SU UBMENU [C CM Key Usa age] is disp played. Mov ve the curs sor to [CM] with [▲] o or [▼] 7.
  • Page 123 S-702D Chapter 3 To make th he best of [CM] keys 2. T hen, keep pressing t he key [CM until a guid de of [Save e setting t o CM2.] is indic cated. CM2] key bli inks in red a and green.
  • Page 124 Chapter 3 To make the best of [CM] keys CVS-702D 3.1.3 Use [CM] keys as screen mode switching and one touch switch of setting: This is to use [CM] key as screen mode switching normally, and to change to one touch switch of setting when fishing method changes.
  • Page 125 CVS-702D Chapter 3 To make the best of [CM] keys To use [CM] keys normally as [Screen mode switching]: 1. Press the [CM] key that is set as normal in use. In the case of CM1, press [CM1] 2. Change [CM] key to [Screen mode switching] by referring to “To set [CM] key to [Screen mode switching]”, p 3-3.
  • Page 126 Chapter 3 To make the best of [CM] keys CVS-702D - This page intentionally left blank.- 3-12 0093107022-02...
  • Page 127 S-702D Chapte er 4 Useful l operation hapter 4 4 Useful l operat tion 4.1 T Temporary y change of f images fo or better vie In the e images o of echo soun nders, norm mally such v various info rmation is o overlaid as image title,...
  • Page 128 Chapter 4 4 Useful op peration CVS- 702D 4.2.2 Ass sign intende ed operatio on to funct tion keys ([ [F1]/[F2]) The functio ons can be assigned to o [F1]/[F2]: Icon Function Icon unction Shift Digit I Input : VR RM Interval IR (Interfer rence reject...
  • Page 129 S-702D Chapte er 4 Useful l operation Switching of range m mode Ther re are 3 type es of range modes: [Au uto Range], , [Manual] a and [Auto S hift]. [Auto o Range] is s the mode e to switch the depth range auto omatically t...
  • Page 130 Chapter 4 4 Useful op peration CVS- 702D 4.3.2 Sett ting of auto o range [Auto Rang ge] is the fu unction to sw witch depth range auto omatically to o display se ea bottom al lways on the disp played scree When sea bottom fall...
  • Page 131 S-702D Chapte er 4 Useful l operation Func ction to sp pecify the m maximum s search ran ge so as to o reduce d deterioratio on of cycle perio To se et [Soundi ng Limit] a at sea botto om search mode: 1.
  • Page 132 Chapter 4 4 Useful op peration CVS- 702D With [ ] key y, the value moves to la arger digit. With [ ] key y, the value moves to s smaller digit With [▲] key y, the value increases. With [▼] key y, the value decreases 7.
  • Page 133 S-702D Chapte er 4 Useful l operation 3. Pr ress [ENT] k . Range Mo ode is set a t [Auto Shif When [Auto o Shift] is s et, [Auto S hift] is disp layed in the e header di isplay show wing Range Mode.
  • Page 134 Chapter 4 4 Useful op peration CVS- 702D 4.4 To use e event key [Event] ke an be switc ched over among 3 f functions: [ [Store Posi ition] to re gister waypoints and to outp put the posit tion informa ation extern ally as TLL data, [Store...
  • Page 135 S-702D Chapte er 4 Useful l operation 4.4.3 3 Starting up Homing To en nable [Hom ming], it is n necessary to o input latit ude/longitud de data suc ch as GGA A, RMC and of NMEA01 183. 1. W hen [Event] ] key is pressed,...
  • Page 136 Chapter 4 4 Useful op peration CVS- 702D 4.4.4 Sele ection of ev vent key fu unction To select f function of f [Event] ke 1. Press [S SUBMENU] 2. The SUB BMENU is d displayed. M Move the cu ursor to [Sy stem] with [ [▲] or [▼] k...
  • Page 137 S-702D Chapte er 4 Useful l operation 5. Pr ress [ ] of 6. Th he SUBMEN NU [Event K Key Usage] is displaye ed. Select a function to be set with h [▲] or [▼] 7. W When [MENU U] key is presse ed, the SUB...
  • Page 138 Chapter 4 4 Useful op peration CVS- 702D 4.5 Short tcut to rang ge registra ation menu When the registered r range in use e is to be ch hanged, the ere is a sho rtcut functio on to chang ge the registered range direc...
  • Page 139 S-702D Chapte er 4 Useful l operation To move th he position n of menu MENU or S SUBMENU i s displayed d half transp parent at the e upper left of the scree en, overlaid on ec cho images Ther re is a funct ion to move...
  • Page 140 Chapter 4 Useful operation CVS-702D - This page intentionally left blank.- 4-14 0093107022-02...
  • Page 141 CVS-702D Chapter 5 Index Chapter 5 Index A Scope ............... 4-2 Depth range ..........4-3, 4-4 Absorption attenuation ........2-64 Depth Unit ............4-2 Adjustment of gain ..........2-25 Diffusional attenuation ........2-64 Alarm range bar .......... 1-13, 4-1 Dust ............2-80, 2-83 All Screens Same ......
  • Page 142 Chapter 5 Index CVS-702D Mixed image ..........2-15, 2-16 Header display ....1-11, 3-2, 3-6, 3-10, 3-11, ..........4-1, 4-3, 4-4, 4-7 Nav Start .............. 4-2 Header Display ...........1-12 NAV1 ..............4-9 High frequency ............ 3-5 Navigation calculation .......... 4-9 Homing ............
  • Page 143 CVS-702D Chapter 5 Index Register shift ............2-41 Synchronized gain ........2-25, 2-51 Registered range ..........4-12 Synchronized mode ........... 2-46 Retroactive Gain ..........2-54 System ........1-12, 3-3, 3-7, 4-10 RMC .............. 4-8, 4-9 Time marker ............1-13 Scale ..............1-13 TLL ..............
