  • Page 2 No part of this publication may be reproduced, transmitted, translated in any form by any means without the written permission of Koden Electronics Coo., Ltd. The technical descriptions contained in this publication are subject to change without notice. Koden assumes no responsibility for any errors, incidentals or consequential damages caused by misinterpretation of the descriptions contained in this publication.

  • Page 3: Important Notice

    Koden is not liable for damages of accompaniment (change/loss of memorized content, loss of business profit, stop of business) arisen from use or failure of our products.  If the stored data are changed or lost, irrespective of causes of troubles and damages, Koden is not liable for them. ...

  • Page 4: For Your Safe Operation

    CVS-FX1 For Your Safe Operation For Your Safe Operation Symbol used in this Installation Manual The following graphical symbols are used in this manual. The meaning of each symbols shall be well understood and apply at maintenance and inspection works.
  • Page 5 For Your Safe Operation CVS-FX1 Caution on location of equipment Do not install the equipment where it is excessively damp and suffers Caution from excessive water drops. Measures against static electricity The static electricity may be generated from the carpet on the floor in Caution the cabin or clothes made of synthetic fiber.

  • Page 6: Table Of Contents

    Selection of location for installation ..................1-1 1.1.4 Laying and connection of cables ................... 1-2 1.1.5 Coordination after installation ....................1-2 Installation of CVS-FX1 Display unit ..................1-3 1.2.1 Desk-top installation....................... 1-3 1.2.2 Flush-mount installation ......................1-5 Installation of transducer......................1-6 1.3.1...
  • Page 7 Contents CVS-FX1 Diagnostics of troubles ......................3-2 3.4.1 Necessary information for requesting repair ................3-2 3.4.2 Diagnostics test........................3-3 3.4.3 LCD Test..........................3-4 3.4.4 Initialize ..........................3-4 3.4.5 Update of program ......................... 3-4 If you suspect a trouble ......................3-6...

  • Page 8: System Configuration

    CVS-FX1 System Configuration System Configuration Connection diagram Legend Standard configuration Option Display unit CVS-FX1 Owner supply With mounting bracket and hard cover J1 connector External echo sounder (Owner supply) CW-371-5M CW-372-5M J2 connector Speaker with amplifier (Owner supply) CW-264A-2 connector...

  • Page 9: Configuration Of Equipment

    Full Menu Reference CVS-FX1.FM.E English Quick Reference CVS-FX1.QR.E English Installation manual CVS-FX1.IM.E English CVS-FX1.ML.E CVS-FX1 Menu List English With 5P connector and one CW-836-3M end soldering to insert to JB Transducer cable For connection of water CW-844-3M temp. and speed sensors viii...
  • Page 10 CVS-FX1 Configuration of Equipment Type of transducer Beam width Material/ Mounting (- 6 dB) Specification Frequency output Cable length/ method (Right and left x Cable diameter Back and forth)(-6 dB) TDM-052 Low frequency (38 kHz) 27° × 14° Low frequency (60 kHz) 18°...
  • Page 11 Configuration of Equipment CVS-FX1 TDM-052 Beam Angle Koden TDM-052 Transducer Beam width to -6 dB points Beam Width Athwartships Beam Width Fore & Aft Beam Width Average (Low Freq.) Beam Width High Frequency Frequency (kHz) TDM-062 Beam Angle Koden TDM-062 　Transducer...
  • Page 12 CVS-FX1 Configuration of Equipment Option List Name of Item Specification Remark Weight/ Length Power rectifier PS-010 Fuse (5A) 2 pcs. AC power cable VV-2D8-3M Both ends plain. Cable configuration is the same as Specify Transducer TDM-052/TDM062. (Refer to length at...

  • Page 13: Dimensions

    Dimensions CVS-FX1 Dimensions (5 11/18) 320.7 (12 5/8) (1 3/16) (3 11/16) (13/16) 30.5 (14 21/64) (1 3/16) (5 29/32) Unit: mm (inch) 0092601112-01...

  • Page 14: Specifications

    CVS-FX1 Specifications Specifications 0092601112-01 xiii...

  • Page 15: Chapter 1 Installation

    (2) Inspection of composition units, spare parts, accessories and installation materials. (3) Checking of supply voltage and current capacity (4) Selection of location for installation (5) Installation of CVS-FX1 Display unit and transducer (6) Attachment of accessories (7) Planning and implementation of cable laying and connection (8) Coordination after installation 1.1.1...

  • Page 16: Laying And Connection Of Cables

    (1) Keep the transducer and power cable as far away from the cables of other electronic equipment as possible. (2) The cabinet of CVS-FX1 Display unit shall be securely grounded to the hull, using the grounding terminal on the rear panel.

  • Page 17: Installation Of Cvs-Fx1 Display Unit

    CVS-FX1 Chapter 1 Installation 1.2 Installation of CVS-FX1 Display unit CVS-FX1 Display unit can be installed either on desk-top or flush-mounted. Install in the following procedure 1.2.1 Desk-top installation (1) Decide the location to install the Display unit and keep the space for the maintenance works as shown in Fig.
  • Page 18 Chapter 1 Installation CVS-FX1 Caution: At installing on desktop, keep the maintenance space is required as shown below. 320.7 (3 15/16) (3 15/16) (12 5/8) (5 25/32) (5 25/32) Fig. 1.3 Maintenance space Unit: mm (inch) 0092601112-01...

  • Page 19: Flush-Mount Installation

    CVS-FX1 Chapter 1 Installation 1.2.2 Flush-mount installation (1) Make a square hole at the location to be installed (See Fig. 1.5) (2) Remove four plastic corner caps of the Display unit (These can be easily pulled out upwards). (3) Confirm that the unit matches the square holes. If not matched, correct the square hole.

  • Page 20: Installation Of Transducer

    Chapter 1 Installation CVS-FX1 1.3 Installation of transducer 1.3.1 In the case of inner hull installation 1) In the case of steel boat With reference to the figures below, install the transducer at a shipyard. Conduit pipe (SGP -1 1/2)
  • Page 21 CVS-FX1 Chapter 1 Installation About installation: Caution: 1. Plumbing pipe and welded plate or rod in dotted lines shall be provided by the shipyard after specifying the details. 2. Preferably larger amount of protruding could produce better performance. (19 3/32) Transducer 4-φ12...
  • Page 22 Chapter 1 Installation CVS-FX1 2) In the case of wooden and FRP boat With reference to the figures below, install the transducer at a shipyard. Cable gland Pedestal Hull plate Float Transducer Hull plate Protruding amount More than 230mm Fixing bolts Unit: mm (inch) Fig.
  • Page 23 CVS-FX1 Chapter 1 Installation (19 11/16) 4-φ12 (15/32) (17 23/32) (4 9/64) Fig. 1.9 Outline view of the unit on FRP and wooden boat Unit: mm (inch) 0092601112-01...
  • Page 24 Chapter 1 Installation CVS-FX1 ・Outline dimensions and specifications of transducers (TDM-052 and TDM-062) (4 9/64) φ11.8 (φ15/32) φ26.5 (φ13/64) (14 31/64) (13 45/64) (R63/64) (R19/32) Unit: mm (inch) Fig. 1.10 Outline dimensions of a transducer (TDM-052 and TDM-062) Specifications of transducers (TDM-052 and TDM-062) Cable length: 15 m (590 35/64) TDM-052: 11.0 kg (24,5 lb)

  • Page 25: Wiring

    CVS-FX1 Chapter 1 Installation 1.4 Wiring 1.4.1 Connection of cables to Display unit Connect the power cable and cables from the transducer to the connectors on the Display unit. (J1) ● External synchronous input/output External echo sounder (J2) ● Sona-Tone...
  • Page 26 Chapter 1 Installation CVS-FX1 Pin assignment of rear connectors Pin assignment viewed from the rear of Display unit: 1 : R POWER 2 : R-GND 3 : G 1 : Power - 4 : G-GND 2 : Power + 5 : B...
  • Page 27 CVS-FX1 Chapter 1 Installation Connection of power cable (CW-270-2M) Connect the power cable to the [POWER] connector at the rear of the Display unit. Connection of DC power cable (CW-270-2M) White Power input + Black To [POWER] connector Power input -...
  • Page 28 2) Connect CW-836-3M after the above processing to J7 connector of CVS-FX1. Connect CW844-3M after the above processing to J6 connector of CVS-FX1. Shield...
  • Page 29 CVS-FX1 Chapter 1 Installation Caution: Wind the insulation tape around the un-used lead wire for core-wires not to contact each other. * As for the shield of transducer to be connected with the shield of CW-836-3M, the 3 of outer shield, low frequency shield and high frequency shield shall be bundled and connected.
  • Page 30 Chapter 1 Installation CVS-FX1 In the case of connection via the junction box (JB – 34): 1) Connect CVS-FX1 and the cable connected to the junction box (JB-34) CW-844-3M Shield Green To J6 connector of CVS-FX1 Orange Blue White Black...
  • Page 31 CVS-FX1 Chapter 1 Installation 2) Connect the transducer (TDM-052 / TDM-062) and the junction box (JB-34). Cable of the transducer is configured as shown in Fig. 1.16. Referring to Fig. 1.17, connect the cable to the junction box (JB-34). Shield Water Temp.
  • Page 32 Chapter 1 Installation CVS-FX1 Connection table of transducers (TDM-052/TDM-062) Junction box Transducer CVS-FX1 (JB-34) (TDM-052/TDM-062) Signal name at Connection to: Color of cable Remarks connection to: Red/TD1H TD1H Blue (high frequency transducer) Green/TD2H High frequency TD2H Black (high frequency transducer)
  • Page 33 Fig. 1.18 External trigger Connection with navigation equipment (J3, J8) The NMEA data can be output from CVS-FX1 to an external navigation equipment, and the NMEA data can be input from an external navigation equipment to CVS-FX1. Refer to the following for the connection.
  • Page 34 Fig. 1.20 Connection of External Monitor Connection of CCD camera (J4) [Owner supply] CVS-FX1 and a CCD camera (NTSC/PAL/SECAM) can be connected via CW-405-0.3M (option). Connect the video output terminal (RCA plug (In most cases, yellow)) of your CCD camera. Perform the waterproof treatment on the junction of the RCA terminal with a self-fusion tape.

  • Page 35: List Of Input/Output Sentences

    CVS-FX1 Chapter 1 Installation 1.5 List of input/output sentences 1.5.1 Input sentence The sentences of GGA, GLL, HDT, MTW, MWV, MWD, RMC, VHW, VTG and ZDA can be received. Possible input formats are: NMEA0183 Ver.1.5, Ver.2.0 and Ver.3.00 Information Priority Order of sentence...

  • Page 36: Chapter 2 Adjustment

    CVS-FX1 Chapter 2 Adjustment 5. Press [ Chapter 2 Adjustment When [Broadband Type] is selected, the setup box of [Broadband Type] will be 2.1 Setup of transducer displayed. The frequency and beam angle etc. per transducer will be conformed to those of the transducer to be used, then, the correct information can be provided.

  • Page 37: Setup Of Frequency Of Transducer

    Chapter 2 Adjustment CVS-FX1 frequency transducer is not used, select The setup box of [Frequency] will be [OFF]. displayed. 5. Press [ ]. When [Broadband Type] is selected, the setup box of Broadband Type will be displayed. 6. Press [▲] or [▼] to select [Frequency].

  • Page 38: Setup Of Beam Angle Of Transducer

    CVS-FX1 Chapter 2 Adjustment beam angle will be automatically set at 3. Press [ ] of setup of frequency. 7. Press to close the menu. The setup box of [LF TD2 Setting] will be displayed. Caution: The setup of beam angle is 4.

  • Page 39: Setup Of Bottom Limit

    Chapter 2 Adjustment CVS-FX1 4. Press [▲] and [▼] to set a depth. Caution: The setup of beam angle is reflected on the display of detecting 5. Press to close the menu. range and will not change the actual beam angle.

  • Page 40: Setup Of Gain (Td) For Transducer

    CVS-FX1 Chapter 2 Adjustment side upper corner of the Gain (TD) setup 2.6 Setup of Gain (TD) for box, the red lighted gain knob shall be transducer operated. When there is a green square mark, turn the green lighted gain knob.

  • Page 41: Setup Of Output Limit For Transmitter

    Chapter 2 Adjustment CVS-FX1 Select [Spc. Adj.] - [Output Limit HF]. 2.7 Setup of Output Limit for transmitter 3. Press [ ] of This is to set the output limit in the following cases: The setup box of [Output Limit HF] will be 1.When you examine standard TD...

  • Page 42: Relation Of The Set Value Between [Output Limit] And [Menu] - [Echo Adjust] - [Tx Power]

    CVS-FX1 Chapter 2 Adjustment 4. Press [▲] or [▼] to set an output limit. Caution: Set the value at 20 for the examination of TDM-052/062 in the air. Set the value at 60 for the transducer of 1kW. 5. Press to close the menu.

  • Page 43: Chapter 3 Maintenance

    CVS-FX1 Chapter 3 Maintenance Chapter 3 Maintenance 3.1 Inspection The daily maintenance and inspection extend the life of equipment. To keep the equipment always in the best conditions, implement the periodical inspection shown in the table below. Item Inspection item...

  • Page 44: Transducer

    Chapter 3 Maintenance CVS-FX1 3.2.2 Transducer In the case of the through-hull installation, check the surface of opening of transducer (portion from which the ultra-sonic is emitted). If shells or oil adhere, scrub the surface with a wooden or bamboo knife with caution not to damage the surface and remove stuck materials. If you scrub strongly, the surface will be damaged, resulting in deteriorated performance of transducer.

  • Page 45: Diagnostics Test

    CVS-FX1 Chapter 3 Maintenance screen will change in color. The same key is 3.4.2 Diagnostics test pressed subsequently, the System Test As self diagnostics, panel test and LCD test screen will end and the setup box of [System can be performed.

  • Page 46: Lcd Test

    Chapter 3 Maintenance CVS-FX1 range, alarm will sound and an alarm The setup box of [Initialize] will be message will be displayed. displayed. When the voltage falls in abnormal range, the indication will be in red. (8) [TEMP] displays water temperature of the water temperature sensor.
  • Page 47 CVS-FX1 Chapter 3 Maintenance 2. Select [Maintain] – [System Program Load]. 3. Press [ ] of The setup box of [System Program Load] will be displayed. 4. When [Yes] is selected, program will be in updating condition message “Updating Do not Power Off.” will be displayed.

  • Page 48: If You Suspect A Trouble

    Chapter 3 Maintenance CVS-FX1 3.5 If you suspect a trouble Symptom Possible cause of trouble Measure  Fuse is blown.  Replace the fuse (See “3.3 Even with power on, nothing is displayed.  Power voltage is out of Fuse Replacement”, page 3-2.
