Owner's Manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 50-1698
S/N: _____________
STAMINA PRODUCTS
MADE IN CHINA
© 2019 Stamina Products, Inc.
2019, 07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Tower 1698 and is the answer not in the manual?

Questions and answers

Related Manuals for Stamina Power Tower 1698

Summary of Contents for Stamina Power Tower 1698

  • Page 1 Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N Alliance Ave, Springfield, MO 65803 Customer Care © 2019 Stamina Products, Inc. 1 (800) 375-7520 2019, 07 www.staminaproducts.com...

  • Page 2: Table Of Contents

    6. It is recommended that you place this exercise equipment on an equipment mat. 7. Set up and operate the Stamina® Power Tower 1698 on a solid level surface. Do not position the Stamina® Power Tower 1698 on loose rugs or uneven surfaces.
  • Page 3 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 4: Before You Begin

    Too often, our busy lifestyles limit our time and questions or problems with the parts included with opportunity to exercise. The Stamina® Power your Stamina® Power Tower 1698, please do not Tower 1698 provides a convenient and simple return the product. Contact us FIRST!

  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Stamina® Power Tower 1698. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels.

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3 There is an “R” decal on the RIGHT DIP ARM(9), and an “L” decal on the LEFT DIP ARM(10). Insert the LEFT DIP ARM(10) onto the LOWER UPRIGHT(3) on the left side and lock in position with the ADJUSTMENT KNOB(19).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5 There is an “R” decal on the RIGHT UPPER SUPPORT(5), and an “L” decal on the LEFT UPPER SUPPORT(7). Refer to illustration A. Insert a UPRIGHT(11) into the LOWER UPRIGHT(3) on the right side. Insert the RIGHT UPPER SUPPORT(5) into the RIGHT LOWER SUPPORT(4) and secure with HEX BOLT (M6x1x15mm)(36) and ARC WASHER(M6)(38).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 Attach the PULL-UP BAR(13) to both UPRIGHTS(11) with HEX BOLTS(M10x1.5x50mm)(35) and ARC WASHERS(M10)(37). SECURELY TIGHTEN ALL OF THE BOLTS FROM STEP 1 TO STEP 7. STEP 8 Attach the AB STRAPS(20) to the UPRIGHTS(11) with the HOOKS(21). There are two sets of the D rings on the AB STRAPS(20) that allow you to attach the AB STRAPS(20) with different lengths.

  • Page 11: Storage

    5. Only Stamina Products supplied components should be used to maintain/repair the Stamina® Power Tower 1698. 6. Keep your Stamina® Power Tower 1698 clean by wiping it off with an absorbent cloth after use.

  • Page 12: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 13: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 14: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 15: Parts List

    PARTS LIST PART# PART NAME Left Base Right Base Lower Upright Right Lower Support Right Upper Support Left Lower Support Left Upper Support Cross Bar Right Dip Arm Left Dip Arm Upright Foam Tube Pull-Up Bar Upright Support Plate Base Support Plate Endcap (ø38.1mm) Foot Stand Bushing...

  • Page 16: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance Ave, Springfield, Missouri, USA, MO 65803, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 17: Notes

    NOTES...

  • Page 18: Fax/Mail Ordering Form

    2040 N Alliance Ave, Springfield, MO 65803 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
