Stamina AeroPilates Reformer 266 Owner's Manual

Stamina AeroPilates Reformer 266 Owner's Manual

Less stress, more heart

Advertisement

Owner's Manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 300 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Service
1 (800) 375-7520
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 55-4266
United States and/or
International patents apply
and/or are pending. See
www.staminaproducts.com
for details.
STAMINA PRODUCTS
MADE IN CHINA
© 2013 Stamina Products, Inc.
2013, 05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AeroPilates Reformer 266 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stamina AeroPilates Reformer 266

  • Page 1 This Product is Distributed Exclusively by International patents apply and/or are pending. See www.staminaproducts.com for details. STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2013 Stamina Products, Inc. 1 (800) 375-7520 2013, 05 www.staminaproducts.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Instructions ........2 Maintenance ..........16 Before You Begin ........4 Conditioning Guidelines ......17 Equipment Warning, Caution & Notice Labels ... 5 Warm-Up and Cool-Down ......18 Hardware Identification Chart ....6 Warranty ............. 19 Assembly Instructions ........
  • Page 3: Customer Service

    Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. ONLINE TELEPHONE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. customerservice@staminaproducts.com Tel: 1 (800) 375-7520 Fax: (417) 889-8064 ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071...
  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the AeroPilates® Although Stamina constructs its products with Reformer 266. We take great pride in producing the finest materials and uses the highest standards this quality product and hope it will provide many...
  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the AeroPilates® Reformer 266. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Labels are larger than actual size CAUTION LABEL(58) PINCH POINT CAUTION LABEL(29)
  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 2 Remove your AeroPilates® Reformer 266 from its packaging, placing the product on its side with the LOCKING PIN(26) side upward. Remove the LOCKING PIN(26) and unfold the MAIN FRAME ASSEMBLY separating the half that has the attached LOCKING PIN(26). When completed, the frame should form a "V"...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5 Remove the paper covering from the foam tape inside the FRONT COVER(3) and REAR COVER(4). Place the FRONT COVER(3) over the FRONT FRAME(1). Place the REAR COVER(4) over the REAR FRAME(2). Press the covers securely in place. NOTE: The securing SCREWS(M6x1x35mm)(36) for the PULLEY SET(22) on each side may need to be loosened to allow the REAR COVER(4) to fit securely over the frame.
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 CAUTION: Be careful not to damage the BUNGEE CORD(53) when unfolding the CARDIO REBOUNDER TOP FRAME(51). Unfold the CARDIO REBOUNDER by swinging up the CARDIO REBOUNDER TOP FRAME(51). Insert the MOUNTING COVERS(57) into the space between the BUNGEE CORD(53) and the CARDIO REBOUNDER TOP FRAME(51) at both sides, then secure with the SECURING KNOBS(54), ROUND HEAD BOLTS(M8x1.25x35mm)(55), and ARC WASHERS(M8)(56).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 9 To prevent the CARRIAGE(7) from moving while placing the AeroPilates® Reformer 266 onto its Stand, attach one of the TENSION CORDS(11) in the slot on the FRONT FRAME(1). Refer to the inset drawing. Place the AeroPilates® Reformer 266 onto the Stand as shown in the illustration. NOTE: The rubber feet of the AeroPilates®...
  • Page 12: Operational Instructions

    OPERATIONAL INSTRUCTIONS LOAD ADJUSTMENT There are three TENSION CORDS(11). The resistance of the CARRIAGE(7) can be adjusted by securing the TENSION CORDS(11) in the slots located on the FRONT FRAME(1). SLOTS You can achieve various levels of resistance by securing different combinations of the TENSION CORDS(11) in the slots.
  • Page 13 OPERATIONAL INSTRUCTIONS CUSTOMIZING ROPE LENGTH Ideal rope length will vary depending on your height and limb length. To determine your ideal rope length, begin by placing the hand/foot straps over the shoulder rests as shown below. Adjust the ropes so they are taut.
  • Page 14 The approximate maximum resistance provided by each cord combination is outlined in the chart below. Frequency of use, type of use and user weight will have an effect on the strength of your cords. Over time cord strength will gradually decrease. Replacement cords are available by contacting Stamina customer service at customerservice@staminaproducts.com.
  • Page 15 OPERATIONAL INSTRUCTIONS CARRIAGE WHEEL REPLACEMENT To replace a carriage wheel, first remove the carriage by releasing the cords and sliding the carriage all the way back to the top end or rear frame of the machine. Tip your machine on its side, bend the machine at the hinge, and simply slide the carriage off the frame.
  • Page 16: Storage

    2. Worn or damaged components should be replaced immediately or the AeroPilates® Reformer 266 should be removed from service until repair is made. 3. Verify that the CAUTION LABEL(58) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement CAUTION LABEL(58) if it is missing or damaged.
  • Page 17: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.
  • Page 18: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.
  • Page 19: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520.
  • Page 20: Product Parts Drawing

    PRODUCT PARTS DRAWING BACK FRONT...
  • Page 21: Parts List

    PARTS LIST PART# PART NAME Front Frame Rear Frame Front Cover Rear Cover Footbar Foam Sleeve Carriage Roller Roller Spacer Rubber Stand Tension Cord Support Bushing Stop Bushing Cushion Head Rest Foam Pad Tube Foam Pad Rope Plastic Snap Hook Hand/Foot Strap Hand Grip Pulley Set...
  • Page 22 PARTS LIST PART# PART NAME Lock Washer (M8) Locking Knob Cardio Rebounder Bottom Frame Cardio Rebounder Top Frame Rebounder Mat Bungee Cord Securing Knob Bolt, Round Head (M8 x 1.25 x 35mm) Arc Washer (M8) Mounting Cover Caution Label Front Stand Middle Stand Rear Stand Connection Bar...
  • Page 23: Fax/Mail Ordering Form

    ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
